135
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q354 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q355 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q356 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q357 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q358 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q359 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q360 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q361 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q362 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q363 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q364 4822 130 60354 TRS.C3421 OY 120V 1A
PC1.5W(10W)
HT334212A0
Q365 4822 130 60353 TRS.A1358 OY 120V 1A
PC1.5W(10W)
HT113582A0
Q366 4822 130 10962 TRS.C3856 OPY 15A 130W
LF119
HT338563A0
Q367 4822 130 10963 TRS.A1492 OPY 15A 130W
LF119
HT114923A0
Q368 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q501 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
Q502 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN01 4822 209 83312 IC,TA7317P HC10042050
QN02 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN03 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN09 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
QN11 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN61 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN62 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN63 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN64 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P154- MISCELLANEOUS
K151 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K152 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K153 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K251 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K252 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K253 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K351 4822 130 60795 TRS.KIT,A1358,C3421
O OR A1358,C3421 Y
HK135819C0
K352 4822 130 10964 TRS.KIT,2SA1492/2SC3856
OPY LF119
HK149219A0
K353 4822 130 10965 TRS.KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P164- SPKOUTS SURR
CENTER MULTI
CIRCUIT BOARD
P164- CAPACITORS
CN13 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN98 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN99 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
P164-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : C159 C160 C259
C260 C359 C360
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C140[/N/S] C169[/N/S]
C240[/N/S] C269[/N/S]
C369[/N/S]
P164- RESISTORS
R188 4822 053 10109 10
Ω
±5% 1W GA05100010
R288 4822 053 10109 10
Ω
±5% 1W GA05100010
R388 4822 053 10109 10
Ω
±5% 1W GA05100010
RN36 4822 116 83929 220
Ω
±5% 1/4W GG05221140
RN38 4822 116 83929 220
Ω
±5% 1/4W GG05221140
RN39 4822 116 83929 220
Ω
±5% 1/4W GG05221140
P164- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN33 RN34
P164- SEMICONDUCTORS
DN06 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN08 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN09 4822 130 82421 DIODE,1D3 1A/200V HD20002710
QN07 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
P164- MISCELLANEOUS
J199 9965 000 12663 TERMINAL,SPKROUT
CENTER SL SR
YT01060030
J299 9965 000 12664 TERMINAL,SPKROUT ML MR YT01040880
LN02 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN04 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN05 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
P604- DSP AND µ-COM
CIRCUIT BOARD
P604- CAPACITORS
C610 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C611 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C612 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C613 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C614 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C615 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C616 4822 126 11568 CER.CHIP,470pF (GR39) DK96471300
C617 4822 126 11703 CER.CHIP,0.01µF DK98103300
C618 4822 124 90357 ELECT.2.2µF ±20% 50V RA-2 OA22505020
C619 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C620 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C621 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C622 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C640 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C641 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C642 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C643 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C644 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
C645 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C646 4822 126 11568 CER.CHIP,470pF (GR39) DK96471300
C647 4822 126 11703 CER.CHIP,0.01µF DK98103300
C648 4822 124 90357 ELECT.2.2µF ±20% 50V RA-2 OA22505020
