136
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C649 4822 126 11687 CER.CHIP,0.1µF GRM39F104Z16 DK98104200
C650 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C651 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C652 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C670 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C671 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C672 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C673 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C674 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C675 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C676
4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C685
C691 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C692 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
C693 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR30 4822 122 33785 CER.CHIP,68pF (GR39) DD95680300
CR31 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR32 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR33 4822 126 11568 CER.CHIP,470pF (GR39) DK96471300
CR34 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR35 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR36 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR44 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR50 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR51 4822 126 11703 CER.CHIP,0.01µF DK98103300
CR52 4822 126 11703 CER.CHIP,0.01µF DK98103300
CR53 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR54 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR55 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR56 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR57 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR58 4822 122 33761 CER.CHIP,22pF ±5% CG 50V
GR39
DD95220300
CR59 4822 122 33761 CER.CHIP,22pF ±5% CG 50V
GR39
DD95220300
CR60 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR61 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR62 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR63 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR64 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CR70 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU01 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU02 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU03 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU04 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU05 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU06 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU07 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU08 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU09 4822 126 11568 CER.CHIP,470pF (GR39) DK96471300
CU12 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU13 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU14 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU15 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU16 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU17 4822 124 90352 ELECT.10µF ±20% 16V RA-2 OA10601620
CU18 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU19 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU20 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU21 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU25 5322 126 11578 CER.CHIP,1000pF ±10% B 50V
GR36
DK96102300
CU26 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU27 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU31 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU32 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU33 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU34 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU35 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU36 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU37 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU38 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU39 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU40 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CU41 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU42 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU43 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU44 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU45 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU46 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU47 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU50 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU51 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU52
4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU60
CU61 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
CU62 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU63 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU64 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
CU70 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU71 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU80 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
CU81 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16 DK98104200
P604- RESISTORS
R601
4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
R607
R610 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R611 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R614
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R623
R624 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R626 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R629 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R630 4822 051 30333 CHIP,33k
Ω ±5% 1/16W NN05333610
R631 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R632 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R633 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R636 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R637 4822 051 30109 CHIP,10
Ω ±5% 1/16W NN05100610
R638 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R640 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R641 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R644
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R653
R654 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R656 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R657 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R658 4822 051 30333 CHIP,33k
Ω ±5% 1/16W NN05333610
R659 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R660 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R661 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
