Marantz SR9200 - Page 108

138
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
Q640 9965 000 12653 IC,CS493292 AUDIO DSP
CRYSTAL
HC10009880
Q641 9965 000 04635 IC,TC74VHCT245AFT HC009805K0
Q671 9965 000 12654 IC,4M FLASH FPT-48P-M19 HC60021000
Q673 9965 000 12655 IC,TC74VHCT244AFT HC009705K0
Q674 9965 000 04636 IC,TC74VHC574FT HC009605K0
Q675 9965 000 04636 IC,TC74VHC574FT HC009605K0
Q676 9965 000 04635 IC,TC74VHCT245AFT HC009805K0
Q680 9965 000 11670 IC,TC74VHCT541AFT HC008805K0
Q681 9965 000 04639 IC,TC74VHC08FT TAPING HC008205K0
Q682 9965 000 12656 IC,TC74VHC32FT HC009505K0
Q683 9965 000 04632 IC,TC74VHC00FS HC005105K0
Q684 9965 000 12656 IC,TC74VHC32FT HC009505K0
Q685 9965 000 12646 IC,TC74VHC125FT HC009405K0
QR44 9965 000 04639 IC,TC74VHC08FT TAPING HC008205K0
QR50 9965 000 06294 IC,LC89055
(SPDIF RECORDER)
HC10405030
QR70 9965 000 11670 IC,TC74VHCT541AFT HC008805K0
QU01 9965 000 12345 IC,H8S/2633 FP-128 HC60022010
QU02 9965 000 11677 IC,PST600D-2 RESET IC
TAPING
HC10098550
QU03 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU05 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU20 9965 000 04632 IC,TC74VHC00FS HC005105K0
QU21 9965 000 12646 IC,TC74VHC125FT HC009405K0
QU41 9965 000 01771 IC,PQ30RV11 HC36930320
QU42 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU43 9965 000 09110 TRS.2SA950 (GR,R) HT109501A0
QU50 9965 000 12346 IC,HIN202ECB 16LEAD
WIDE BODY
HC10204990
QU60 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU61 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU62 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU63 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU65 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU66 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU67 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU68 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU69 4822 130 90347 PHOTO CUPLER,PC-817 1PAIR HW10006320
QU70 9965 000 12647 IC,ATMEL AT24C08 8PIN SOIC HC10191990
QU71 5322 209 11578 IC,PCF8574I(I/O EXPANDER) HC10068490
QU80 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
QU81 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU82 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU83 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
QU84 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
QU85 4822 111 92183 DIG.TRS.RN2303
(PNPX1(22K+22K))
BA10013050
QU86 4822 130 61553 DIG.TRS.DTC124EU,RN1303
UMT TYPE
BA21303000
P604- MISCELLANEOUS
JR30 4822 265 10328 TERMINAL,14X14 RA 1L1P BLK
NI FLM-GND
YT02010780
JR31 9965 000 12657 OPT.CONNECTOR,
JFJ300 OPT OUTPUT
YJ15000210
JU50 9965 000 12342 JACK,DELC-J9PAF-20L9 YJ90001220
JU61 4822 267 41009 TERMINAL,2P CINCH PINJACK YT02020890
JU62 9965 000 12343 TERMINAL,CINCH PIN JACK
GRN-GRN
YT02021740
JU80 9965 000 12344 JACK,3.5MM MINI JACK
LGA6502-0150
YJ01004750
JU82 9965 000 03411 JACK,3.5 MINI JACK
LGY6501-0600
YJ01004670
L691 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LR30 4822 142 60422 PULSE TRANSF
(TPS247MN-0386AN)
TP41042030
LU01
9965 000 05005 FERRITE CORE,
BK1608HM102-T BEADS
FC90020120
LU54
LU71
9965 000 05005 FERRITE
CORE,BK1608HM102-T BEADS
FC90020120
LU80
LU81
4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LU86
LU87 9965 000 05005 FERRITE CORE,
BK1608HM102-T BEADS
FC90020120
SU02 9965 000 12347 PUSH SW.(SPUJ191000)
W/KNOB
SP02022320
XR50 4822 242 10851 CRYSTAL,12.288MHZ (AT-49) JX12013260
XU01 9965 000 12348 SERAMIC VIB.CSTLS 5.0MHZ FQ05004050
P814- BACKUP TRANSF,
AC OUTLET
CIRCUIT BOARD
P814- CAPACITORS
C802 9965 000 06706 CER.DE1607-1F 103M-KH DK17103910
C805 4822 124 90351 ELECT.0.1µF ±20% 50V RA-2 OA10405020
C811 4822 124 23649 ELECT.470µF 25V ±20% RA-2 OA47702520
C812 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
C813 4822 124 80582 ELECT.4700µF 16V RA2 OA47801620
C814 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C815 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C816 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C817 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
P814- RESISTORS
R807 4822 117 10158 1
Ω ±5% 1/4W GG05010140
R811 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R899 /U 2.2M Ω ±10% 1/2W FOR UL RC10225820
P814- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R805 R806 R812
R813
P814- SEMICONDUCTORS
D802 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D804 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D811
4822 130 82421 DIODE,1D3 1A/200V HD20002710
D816
