139
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
D817 4822 130 80317 ZENER,5.1V EQUIVALENT HD30511000
Q802 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q803 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
Q811 4822 209 61847 IC,NJM78M05FA HC38505090
Q812 9965 000 11677 IC,PST600D-2 RESET IC
TAPING
HC10098550
P814- MISCELLANEOUS
F801 /N 4822 070 35002 FUSE,5A 250V BS LI STED FS10500850
F801 /S FUSE,5A 250V BS LI STED FS10500850
F801 /U FUSE,10A 250V GGL10,
GBM10 /U/C/D
FS11000530
J801 /N 4822 267 31194 JACK,AC SOKET YKE31-0090 YJ04001640
J801 /U JACK,2P AC OUTLET
(CCT1304-0212)
YJ04002040
J806 TERMINAL,M1698
PWB GND TERMINAL WITH M3
YL01010140
L801 4822 280 80773 RELAY,VS24MB-NR TV-8 LY10240240
L811 /N/S 9965 000 12339 POWER TRANSF.BACKUP
AC230V
TS13521080
L811 /U POWER TRANSF.BACKUP
AC120V
TS13521070
P824- POWER SW
(EXEPT /U)
CIRCUIT BOARD
P824- CAPACITORS
C801 /N/S 9965 000 06706 CER.DE1307-1E 472M-KH DK17472910
P824- MISCELLANEOUS
S801 /N/S 9965 000 11695 PUSH SW.AC POWER
ESB92S17B
SP01013800
P834- POWER SUPPLY
FOR POWER AMP
CIRCUIT BOARD
P834- CAPACITORS
C511 4822 126 10364 CER.100pF UP050B101K-A DA16101110
C514 4822 124 23056 ELECT,47µF/16V EJ47601610
C831 4822 124 23918 ELECT.ELNA RA2 16X25 OA10805020
C832 4822 124 41542 ELECT.470µF ±20% 50V RA-2 OA47705020
C833
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C836
C837 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C838 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C839 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C840 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C841 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C842 9965 000 12713 ELECT.35XL80 VNSD OB27906330
C843 9965 000 12713 ELECT.35XL80 VNSD OB27906330
C846 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
C847 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C848 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN07 4822 124 90366 ELECT.220µF ±20% 50V RA-2 OA22705020
CN08 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN09 4822 126 10364 CER.100pF UP050B101K-A DA16101110
P834-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : C512
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C513
P834- RESISTORS
R538 4822 052 10331 330
Ω
±5% 1/4W GG05331140
R539 4822 052 10331 330
Ω
±5% 1/4W GG05331140
R831 4822 050 21021 100
Ω
±5% 1/4W GG05101140
R832 4822 050 21021 100
Ω
±5% 1/4W GG05101140
R833 4822 050 21108 1
Ω
±5% 1/2W GG05010120
R834 4822 117 10158 1
Ω
±5% 1/4W GG05010140
R835 4822 052 10101 100
Ω
±5% 1/6W GG05101160
RN24 4822 117 10158 1
Ω
±5% 1/4W GG05010140
P834- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R536 R537
R551-R563 RN25 RN26 RN46
P834- SEMICONDUCTORS
D501 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D502 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D503 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D831
4822 130 82421 DIODE,1D3 1A/200V HD20002710
D838
D839 4822 130 81729 ZENER,MTZJ33D HD33301000
D840 4822 130 80318 ZENER,6.8V EQUIVALENT HD30681000
D841 9965 000 01578 DIODE,600V 25A BRIDGE-DI
D25XB60
HE20029290
DN01 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN02 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN03 4822 130 82609 ZENER,MTZJ2.0B HD30201000
DN04 4822 130 82609 ZENER,MTZJ2.0B HD30201000
Q503 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q504 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q505 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K, 10K
BA20001000
Q506 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q507 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q508 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q831 4822 209 80675 IC,NJM78M18FA HC38518090
Q832 4822 209 83829 IC,18V 500MA REG.
NJM79M18FA JRC
HC39518090
Q833 4822 209 80675 IC,NJM78M18FA HC38518090
P834- MISCELLANEOUS
L501 9965 000 12665 RELAY,VSB24STB 16A AVSS LY10240300
L502 9965 000 12665 RELAY,VSB24STB 16A AVSS LY10240300
P844- AC INLET
CIRCUIT BOARD
P844- MISCELLANEOUS
J810 9965 000 01313 JACK,2P AC INLET PWI1910-H YJ04002440
PC04- FRONT
CIRCUIT BOARD
PC04- CAPACITORS
CC01
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC05
CC07 CER.390pF DA16391110
CC08 4822 126 10364 CER.100pF UP050B101K-A DA16101110
To Next Page
