140
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CC09 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC10 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC11 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC12 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC13 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC16 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC17 4822 122 30103 CER.0.022µF Z 50V DK18223310
CC18 4822 124 21901 ELECT,47µF/6.3V EJ47600610
CC21 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC22 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC30 4822 124 80665 ELECT,10µF/50V EJ10605010
CC31 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC32 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC33 4822 126 11558 CER.0.1µF Z 50V DA17104110
CC34 4822 124 21894 ELECT,10µF/16V EJ10601610
CC35 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC36 4822 126 10935 ELECT,100µF/6.3V EJ10700610
CC38 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC40 4822 122 40586 CER.10000pF DA17103110
CC41 4822 122 40586 CER.10000pF DA17103110
CC43 4822 126 10935 ELECT,100µF/6.3V EJ10700610
CC44 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PC04-CAPACITORS(COMMON)
PLASTIC FILM CAPACI TOR
±5% 50V : CC20
PC04- RESISTORS
RC08 COMPO.RKC13BS473J
±5% P1.8
BW05473230
RC09 COMPO.RKC13BS473J
±5% P1.8
BW05473230
RC10 COMPO.RKC13BS103J
±5% P1.8
BW05103330
RC11 COMPO.RKC13BS473J
±5% P1.8
BW05473230
PC04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RC01-RC04 RC06
RC12 RC13 RC16[/U]
RC17-RC21 RC24-RC50 RC52
PC04- SEMICONDUCTORS
DC01 4822 130 82159 L.E.D.GL3ED8 SHARP HI10099320
DC02
9965 000 12659 L.E.D.SLR-932AV-8K A RANK
5MM P2.5
HI20006030
DC05
DC06 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
QC01 9965 000 12660 IC,NJM3430FG1 HC10220090
QC02 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QC03 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QC04 4822 218 12029 PHOTO UNIT,IR SENSOR
TSOP 1136 TB1
HW10002620
QC05 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC06 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC07 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC08 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QC09 4822 130 42292 TRS.2SC2120 O HT321201A0
QC10 4822 130 42292 TRS.2SC2120 O HT321201A0
QC11 9965 000 11677 IC,PST600D-2 RESET IC
TAPING
HC10098550
PC04- MISCELLANEOUS
SC01
9965 000 00373 PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
SC26
SC27 9965 000 01349 ROTARY ENCODER,
EC16B 16PLS 16CLI CK
SR02010080
VC01 9965 000 12661 DISPLAY UNIT,16-BT-92GNK HQ31601410
PC64- STANDBY TACT SW
CIRCUIT BOARD (/U ONLY)
PC64- MISCELLANEOUS
SC60 /U PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
PC74- UP/DOWN SW
CIRCUIT BOARD
(PS9200 ONLY)
PC74- MISCELLANEOUS
SC70 9965 000 00373 PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
SC71 9965 000 00373 PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
PC84- VOLUME ENCODER
CIRCUIT BOARD
PC84- CAPACITORS
CC80 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CC81 4822 122 40586 CER.10000pF DA17103110
CC82 4822 122 40586 CER.10000pF DA17103110
PC84- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RC80-RC85
PC84- MISCELLANEOUS
SC80 9965 000 00373 PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
SC81 9965 000 00373 PUSH SW.
EVQ11L05R H/5MM,160GF
SP01013370
SC82 9965 000 01348 ROTALY ENCODER,
36PULSE EC16B
SR02010070
PD04- DIG IN/ADC/DAC
CIRCUIT BOARD
PD04- CAPACITORS
CA01 4822 126 13837 CER.CHIP,0.1µF ±10% B 10V DK96104200
CA02 4822 126 13837 CER.CHIP,0.1µF ±10% B 10V DK96104200
CA03 4822 126 13837 CER.CHIP,0.1µF ±10% B 10V DK96104200
CA06 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
CA07 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
CA08 4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
CA10 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CA12 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CA14
4822 126 11687 CER.CHIP,0.1µF
GRM39F104Z16
DK98104200
CA20
CD01
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CD04
