143
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RK20 4822 051 30222 CHIP,2.2k Ω ±5% 1/16W NN05222610
RK21 4822 051 30105 CHIP,1M
Ω ±5% 1/16W NN05105610
RK23
4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RK28
RK29 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK30 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK31 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK32 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK33 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK39 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK40 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK41 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK42 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK43 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK44 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK46 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK47 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK48 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK49 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK50 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK51 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK55 4822 051 30563 CHIP,56k
Ω ±5% 1/16W NN05563610
RK56 4822 051 30563 CHIP,56k
Ω ±5% 1/16W NN05563610
RK58 4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RK70
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK73
RK74 4822 052 10681 680
Ω ±5% 1/6W GG05681160
RK75 4822 052 10681 680
Ω ±5% 1/6W GG05681160
RK76 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK77 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
PD04- SEMICONDUCTORS
DA01 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DA02 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DA03 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK01 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK02 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK03 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK70 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK71 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
QA01 4822 209 31568 IC,CMOS 74HCU04 FLAT
TAPING
HC700400Z0
QA03 9965 000 01342 IC,TC74HC151AF HC715100Z0
QA04 9965 000 01342 IC,TC74HC151AF HC715100Z0
QA05 4822 209 31929 IC,OR-GATE 74HC32 HC703200Z0
QA06 4822 209 30426 IC,CMOS 74HC00 FLAT
TAPING
HC700000Z0
QA07 5322 209 11578 IC,PCF8574I(I/O EXPANDER) HC10068490
QD01
9965 000 12651 IC,DAC CS4396-KS 24B IT
DR=120DB
HC10011880
QD04
QH01
4822 209 17155 IC,NJM2068M TAPING HC10102090
QH05
QJ01
4822 209 17155 IC,NJM2068M TAPING HC10102090
QJ04
QK01 4822 130 63601 CHIP TR.(2SC),2SC4213 HX342132A0
QK02 4822 130 63601 CHIP TR.(2SC),2SC4213 HX342132A0
QK03 4822 209 14615 IC,NJM2115M HC10172090
QK04 4822 209 14615 IC,NJM2115M HC10172090
QK05 4822 209 17155 IC,NJM2068M TAPING HC10102090
QK06 4822 209 17155 IC,NJM2068M TAPING HC10102090
QK07 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK08 4822 209 14615 IC,NJM2115M HC10172090
QK52 9965 000 12341 IC,ADC AK5380VT 24BIT 105DB HC10035480
QK70 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK71 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QK72 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK73 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
PD04- MISCELLANEOUS
JA01 4822 265 10682 TERMINAL,YKC21-3779 YT02030420
JA03 9965 000 12658 OPT.CONNECTOR,JFJ400 YJ15000200
JA04 9965 000 12658 OPT.CONNECTOR,JFJ400 YJ15000200
JA05 9965 000 12658 OPT.CONNECTOR,JFJ400 YJ15000200
LD01
4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LD04
LK70 9965 000 01576 RELAY,MR82-24USR LY20240480
LK71 9965 000 01576 RELAY,MR82-24USR LY20240480
PF04- SCART
CIRCUIT BOARD (/N ONLY)
PF04- CAPACITORS
CF81 /N 4822 122 30043 CER.0.01µF Z 50V DK18103310
CF82 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
PF04- RESISTORS
RF83 /N 4822 116 82805 1
Ω ±5% 1/6W GG05010160
PF04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RF81[/N] RF82[/N]
PF04- SEMICONDUCTORS
DF81 /N 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
QF81 /N 4822 130 60839 TRS.2SC2458 (B) HT324582B0
PF04- MISCELLANEOUS
JF81 /N 9965 000 08366 TERMINAL,YKF41-5040 YT02210070
JF82 /N 9965 000 08366 TERMINAL,YKF41-5040 YT02210070
LF81 /N 9965 000 01576 RELAY,MR82-24USR LY20240480
PF14- COMPONENT
CIRCUIT BOARD
PF14- CAPACITORS
CF61 /S/U CER.0.01µF Z 50V DK18103310
CF62 /S/U ELECT.10µF ±20% 50V RA-2 OA10605020
CF63 /S/U ELECT.470µF ±20% 6.3V RA-2 OA47700620
PF14- RESISTORS
RF53 /S/U 1
Ω ±5% 1/6W GG05010160
RF59 /S/U 1
Ω ±5% 1/6W GG05010160
RF76 /S/U 1
Ω ±5% 1/6W GG05010160
RF77 /S/U 75
Ω ±5% 1/6W GD05750160
PF14- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RF51[/S/U]
RF52[/S/U] RF57[/S/U]
RF58[/S/U] RF74[/S/U]
RF75[/S/U]
