Marantz SR9200 - Page 114

144
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PF14- SEMICONDUCTORS
DF51 /S/U DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DF53 /S/U DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DF54 /S/U DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
QF51 /S/U TRS.2SC2458 Y OR GR HT324582B0
QF53 /S/U TRS.2SC2458 Y OR GR HT324582B0
QF54 /S/U TRS.2SC2458 Y OR GR HT324582B0
PF14- MISCELLANEOUS
JF51 /S/U TERMINAL,
YKC21-4075 1L3 FS NI
YT02030710
JF52 /S/U TERMINAL,
YKC21-4310 1L3 FG NI
YT02030720
JF53 /S/U TERMINAL,
YKC21-4310 1L3 FG NI
YT02030720
JF54 /S/U PLUG,08MQ-ST-L YP06902290
LF51 /S/U RELAY,MR82-24USR LY20240480
LF52 /S/U RELAY,MR82-24USR LY20240480
LF56 /S/U RELAY,MR82-24USR LY20240480
LF57 /S/U RELAY,MR82-24USR LY20240480
LF59 /S/U RELAY,MR82-24USR LY20240480
PG04- ELE.VOLUME
CIRCUIT BOARD
PG04- CAPACITORS
CE01 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE02 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE04 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE07 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE09 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE10 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE11 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CE12 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CE13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE19 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE20 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE31 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE32 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE33 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE34 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE49 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CE50 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CE51 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE52 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE53 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE54 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE57 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE58 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE59 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE60 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE61 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CE62 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CE63 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CE64 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE67 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE68 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE69 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE70 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE81 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE82 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CE83 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CE84 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG01 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG02 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG04 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG07 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG09 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG10 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG11 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CG12 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CG13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG19 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG20 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG51 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG52 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG53 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG54 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG57 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG58 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG59 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG60 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CG61 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CG62 9965 000 02015 ELECT.22µF ±20% 25V
ARS-TYPE
OA22602540
CG63 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG64 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CG67 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG68 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CG69 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CG70 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM01 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM02 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM04 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM07 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM09
4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM12
CM13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM19 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM20 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CM31 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM32 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CM33 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM34 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CM37 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
