148
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RL69 4822 116 81011 CHIP,75 Ω ±5% 1/10W NI05750110
RL70 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL72
4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL84
RL85 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
PL04- SEMICONDUCTORS
DL01 4822 130 33944 CHIP DIODE,DAN202K HZ20002210
QF01 9965 000 12718 IC,NJM2534M TAPING TE1 HC10223090
QF02 9965 000 03394 IC,NJM2296M TAPING HC10210090
QF03 5322 209 13551 IC,NJM2535M TAPING TE1 HC10224090
QF04 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QL01 9965 000 12718 IC,NJM2534M TAPING TE1 HC10223090
QL02 9965 000 03394 IC,NJM2296M TAPING HC10210090
QL03 5322 209 13551 IC,NJM2535M TAPING TE1 HC10224090
QL04 4822 209 15524 IC,OSD IC LC74781 HC10377030
QL05 5322 209 13551 IC,NJM2535M TAPING TE1 HC10224090
QL06 9965 000 12719 IC,BA7622F TAPI NG-E2 HC10221210
QL07 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QL08 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QL09 4822 130 42715 TRS.A1048,A933S,A1267,ETC. HT10001000
QL10 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QL11 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QL12 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QL13 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QL14 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QL15 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
QL16 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QL17 /S/U DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QL18 /N/S 4822 130 61189 DIG.TRS.DTC114TS/UN4215
10K
BA20004000
QL19 /N/S 4822 130 61189 DIG.TRS.DTC114TS/UN4215
10K
BA20004000
QL20 /N/S 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QL21 4822 209 30426 IC,CMOS 74HC00 FLAT
TAPING
HC700000Z0
QL22 9965 000 12720 CHIP TR.(2SC),2SC1622AD17 HX316221A0
PL04- MISCELLANEOUS
JL01 9965 000 12715 TERMINAL,YKC21-3893
1L1 FS NI
YT02011700
JL02 9965 000 12716 TERMINAL,YKC21-4101
2L2 FS NI
YT02021720
JL03 9965 000 03415 TERMINAL,14X14 RA
1L3P YEL NI F-GROUND
YT02030590
JL04 9965 000 12717 TERMINAL,YKC21-4344
1L4 FG NI
YT02041320
LL01 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LL02 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LL03 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LL04 9965 000 03404 CHIP INDUCTANCE,
NL252018 33UH
LU15333010
XL01 4822 242 80288 CRYSTAL,AT49/
14.31818MHZ(TP)
JX14001260
XL02 /N/S 4822 242 73903 CRYSTAL,AT49 17.7MHZ JX17001260
PN14- RN47
CIRCUIT BOARD
PN14- RESISTORS
RN47 4822 126 90009 VARISTOR,FOR HEAT SENS.
100C BD
HP00029230
PN24- RN62
CIRCUIT BOARD
PN24- RESISTORS
RN62 9965 000 12666 VARISTOR,FOR FAN SENS.
80C BF
HP00042230
PN54- RN49
CIRCUIT BOARD
PN54- RESISTORS
RN49 4822 126 90009 VARISTOR,FOR HEAT SENS.
100C BD
HP00029230
PN64- RN86
CIRCUIT BOARD
PN64- RESISTORS
RN86 9965 000 12666 VARISTOR,FOR FAN SENS.
80C BF
HP00042230
PP04- AUX
CIRCUIT BOARD
PP04- CAPACITORS
CP01 4822 126 11127 CER.470pF DA16471110
CP02 4822 126 11127 CER.470pF DA16471110
CP03 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CP04 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CP05
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CP08
CP09 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CP11
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CP14
CP16 4822 126 11558 CER.0.1µF Z 50V DA17104110
CP17 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CP18 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PP04- RESISTORS
RP11 4822 111 41355 75
Ω ±5% 1/6W GD05750160
RP12 4822 111 41355 75
Ω ±5% 1/6W GD05750160
RP14 4822 111 41355 75
Ω ±5% 1/6W GD05750160
PP04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RP01-RP06 RP16
PP04- SEMICONDUCTORS
QP01 4822 209 83631 IC,NJM4558D-D HC10008090
PP04- MISCELLANEOUS
JP01 9965 000 12658 OPT.CONNECTOR,JFJ400 YJ15000200
JP02 9965 000 01347 CINCH JACK 3P +S-TERMINAL BY04040030
PP94- H.P.
CIRCUIT BOARD
PP94- CAPACITORS
CP93 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PP94- MISCELLANEOUS
JP99 4822 265 10685 JACK,HLJ2307-01-3160 YJ01004240
