149
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PQ04- A-FUNCTION-V
CIRCUIT BO
PQ04- CAPACITORS
CQ07 4822 126 11127 CER.470pF DA16471110
CQ08 4822 126 11127 CER.470pF DA16471110
CQ13 4822 126 11127 CER.470pF DA16471110
CQ14 4822 126 11127 CER.470pF DA16471110
CQ19 4822 126 11127 CER.470pF DA16471110
CQ20 4822 126 11127 CER.470pF DA16471110
CQ25 4822 126 11127 CER.470pF DA16471110
CQ26 4822 126 11127 CER.470pF DA16471110
CQ31 4822 126 11127 CER.470pF DA16471110
CQ32 4822 126 11127 CER.470pF DA16471110
CQ39 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ40 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ43 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ44 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ48 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ49 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ50
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ53
CQ54
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ58
CQ64 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CQ65 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
PQ04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CQ37 CQ38 CQ41 CQ42 CQ56
CQ59 CQ60-CQ63
PQ04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ09-RQ12
RQ17-RQ20 RQ25-RQ28
RQ33-RQ36 RQ41-RQ44
RQ49-RQ64
PQ04- SEMICONDUCTORS
QQ01 4822 209 16842 IC,NJU7312L ANALOG SWI TCH HC10124090
QQ02 4822 209 16842 IC,NJU7312L ANALOG SWI TCH HC10124090
QQ03 4822 209 83274 IC,NJM4560D-D HC10021090
PQ04- MISCELLANEOUS
JQ01 9965 000 03416 TERMINAL,14X14 RA 2L4
WH+RE NI F-GROUND
YT02041270
JQ02 9965 000 03417 TERMINAL,14X14 RA 2L6
WH+RE NI F-GROUND
YT02060660
JQ03 9965 000 03416 TERMINAL,14X14 RA 2L4
WH+RE NI F-GROUND
YT02041270
PS04- AUDIO FUNCTION
CIRCUIT BOARD
PS04- CAPACITORS
CS07 4822 126 11127 CER.470pF DA16471110
CS08 4822 126 11127 CER.470pF DA16471110
CS13 4822 126 11127 CER.470pF DA16471110
CS14 4822 126 11127 CER.470pF DA16471110
CS19 4822 126 11127 CER.470pF DA16471110
CS20 4822 126 11127 CER.470pF DA16471110
CS27 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS28 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS31 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS32 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS35 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS36 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS37
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS40
CS41
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS45
CS51 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CS52 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
PS04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CS25 CS26 CS29 CS30 CS43
CS46-CS50
PS04- RESISTORS
RS09 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS10 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS11 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS12 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS13 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS14 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS17 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS18 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS19 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS20 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS21 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS22 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS25 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS26 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS27 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS28 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS29 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS30 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS33 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS34 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS35 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS36 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS37 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS38 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS39 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS40 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS41 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS42 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS43 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS44 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS46 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS49 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS51 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS54 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS55 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS56 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
PS04- SEMICONDUCTORS
QS01 4822 209 16843 IC,NJU7313L ANALOG SWI TCH HC10125090
QS02 4822 209 16843 IC,NJU7313L ANALOG SWI TCH HC10125090
QS03 4822 209 83357 IC,NJM4560M HC10029090
