150
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PS04- MISCELLANEOUS
JS01 9965 000 03416 TERMINAL,14X14 RA 2L4
WH+RE NI F-GROUND
YT02041270
JS02 9965 000 03417 TERMINAL,14X14 RA 2L6
WH+RE NI F-GROUND
YT02060660
PS54- MULTI CH INPUT
CIRCUIT BOARD
PS54- CAPACITORS
CQ71 4822 126 11127 CER.470pF DA16471110
CQ72 4822 126 11127 CER.470pF DA16471110
CQ73 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ74 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ75 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ76 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ77 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ78 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ79 4822 126 11127 CER.470pF DA16471110
CQ81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ82 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ83 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ84 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ85 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ86 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ87 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS71 4822 126 11127 CER.470pF DA16471110
CS72 4822 126 11127 CER.470pF DA16471110
CS73 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS74 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS75 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS76 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS77 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS78 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS79 4822 126 11127 CER.470pF DA16471110
CS80 4822 126 11127 CER.470pF DA16471110
CS81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS82 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS83 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS84 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS85 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS86 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS87 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS88 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS89 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS95 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CS96 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
PS54-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CQ80 CS90-CS94
PS54- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ71-RQ74
RQ77-RQ86 RS71-RS74
RS77-RS82 RS85-RS89
PS54- SEMICONDUCTORS
QQ71 4822 209 73064 IC,NJM-2068-DD HC10053090
QQ72 4822 209 73064 IC,NJM-2068-DD HC10053090
QS70 4822 209 16149 IC,NJU7311L ANALOG SWI TCH HC10123090
QS71 4822 209 73064 IC,NJM-2068-DD HC10053090
QS72 4822 209 73064 IC,NJM-2068-DD HC10053090
PS54- MISCELLANEOUS
JS70 9965 000 12714 TERMINAL,YKC21-3925
2L4P FG BK NI
YT02041350
JS71 9965 000 12714 TERMINAL,YKC21-3925
2L4P FG BK NI
YT02041350
PX04- S-VIDEO
CIRCUIT BOARD
PX04- CAPACITORS
CX05
4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CX08
CX09 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX10 4822 124 90358 ELECT.22µF ±20% 16V RA-2 OA22601620
CX11 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX12 4822 124 90358 ELECT.22µF ±20% 16V RA-2 OA22601620
CX25
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX34
CX35 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX36 4822 124 90358 ELECT.22µF ±20% 16V RA-2 OA22601620
CX37 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX38 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX39 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX40 4822 124 90358 ELECT.22µF ±20% 16V RA-2 OA22601620
CX41 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX42 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX44 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX45 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CX46 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CX48 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CX49 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CX51 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CX53 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX54 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX55 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX56 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX57 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX58 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX61 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX62 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX64 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX65 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CX66 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CX68 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CX69 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX71 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CX72 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX73 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX74 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX75 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX79 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CX80 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CX81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX82 4822 122 40588 CER.0.022µF TP050F223Z DA17223110
CX83 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CX84 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX85 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX86 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX87 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX88 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CX89 4822 122 30043 CER.0.01µF Z 50V DK18103310
CX91 4822 126 12696 CER.20pF ±5% CH 50V BLK DD15200300
CX92 4822 126 12696 CER.20pF ±5% CH 50V BLK DD15200300
