151
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CX93 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
PX04- RESISTORS
RX01
4822 111 41355 75
Ω ±5% 1/6W GD05750160
RX04
RX07
4822 111 41355 75
Ω ±5% 1/6W GD05750160
RX20
RX29 4822 111 41355 75
Ω ±5% 1/6W GD05750160
RX37
4822 111 41355 75
Ω ±5% 1/6W GD05750160
RX40
PX04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RX28 RX30-RX34
RX36
PX04- SEMICONDUCTORS
QX01 4822 209 32861 IC,NJM2234D DIP TYPE HC10143090
QX02 9965 000 09133 IC,VIDEO SW NJM2296D
5IN 3OUT
HC10217090
QX03 4822 209 32861 IC,NJM2234D DIP TYPE HC10143090
QX04 9965 000 09133 IC,VIDEO SW NJM2296D
5IN 3OUT
HC10217090
QX05 9965 000 12724 IC,NJM2249D HC10221090
QX06 9965 000 12725 IC,NJM2235D HC10222090
QX07 9965 000 12726 IC,BA7622 DIP HC10220210
PX04- MISCELLANEOUS
JX01 4822 265 20725 2P S TERMINAL YT02021320
JX02 4822 265 10678 TERMINAL,YKF51-5506 YT02011010
JX03 4822 265 31302 3P S TERMINAL YT02030350
JX04 4822 265 31302 3P S TERMINAL YT02030350
LX01 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LX02 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
PY04- CONNECTOR
CIRCUIT BOARD
PY04- CAPACITORS
C851 4822 122 30043 CER.0.01µF Z 50V DK18103310
C852 4822 122 30043 CER.0.01µF Z 50V DK18103310
C853 4822 124 22695 ELECT.2200µF ±20% 35V RA-2 OA22803520
C854 4822 124 22695 ELECT.2200µF ±20% 35V RA-2 OA22803520
C855
4822 122 30043 CER.0.01µF Z 50V DK18103310
C858
C859 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C860 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C861 4822 122 30043 CER.0.01µF Z 50V DK18103310
C862 4822 122 30043 CER.0.01µF Z 50V DK18103310
C863 ELECT,22000µF 10V EA22901010
C864 4822 124 22695 ELECT.2200µF ±20% 35V RA-2 OA22803520
C865
4822 122 30043 CER.0.01µF Z 50V DK18103310
C868
C869 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C870 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C871 4822 122 30043 CER.0.01µF Z 50V DK18103310
C872 4822 122 30043 CER.0.01µF Z 50V DK18103310
C873 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C874 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
C875 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C876 4822 122 30043 CER.0.01µF Z 50V DK18103310
C877 4822 122 30043 CER.0.01µF Z 50V DK18103310
C878 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C879 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
C901 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
C901 /S ELECT.10µF ±20% 50V RA-2 OA10605020
C902 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
C903 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
C903 /S ELECT.10µF ±20% 50V RA-2 OA10605020
C907
/N/S 4822 126 10364 CER.100pF UP050B101K-A DA16101110
C910
C912 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
C912 /S ELECT.10µF ±20% 50V RA-2 OA10605020
C913 /N/S 4822 122 40586 CER.10000pF DA17103110
C914 /N/S 5322 122 32143 CER.22pF ±5% CH 50V BLK DD15220300
C915 /N/S 4822 122 30045 CER.27pF ±5% CH 50V BLK DD15270300
C951 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C951 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C952 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C952 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C955 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C955 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C956 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C956 /S ELECT.4.7µF ±20% 50V RA-2 OA47505020
C957 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C957 /S/U ELECT.4.7µF ±20% 50V RA-2 OA47505020
C958 /N 4822 124 80067 ELECT.4.7µF ±20% 50V RA-2 OA47505020
C958 /S/U ELECT.4.7µF ±20% 50V RA-2 OA47505020
C959 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
C960 /N/S 4822 122 30043 CER.0.01µF Z 50V DK18103310
CM81
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CM85
CT01 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT04 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT05 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT06 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CT07 4822 122 30043 CER.0.01µF Z 50V DK18103310
CT08 4822 122 30043 CER.0.01µF Z 50V DK18103310
CT09 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CW01 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW02 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW03 /N/S 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CW04 /N/S 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CW05 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW06 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW07 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW08 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW31 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW32 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW35 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW36 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CW37 4822 122 30043 CER.0.01µF Z 50V DK18103310
CW38 4822 122 30043 CER.0.01µF Z 50V DK18103310
CY01 4822 122 30043 CER.0.01µF Z 50V DK18103310
PY04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C904-C906[/N/S] C953[/N/S]
C954[/N/S] CM83 CM86 CT02
CT03
