152
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR8200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PY04- RESISTORS
R851 4822 050 21501 150
Ω ±5% 1/4W GG05151140
R852 4822 116 82805 1
Ω 1W GG05010160
PY04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R901-R904[/N/S]
R951-R958[/N/S] R959-R962
RM81 RM83-RM85 RT01 RT02
RW01-RW04 RW31-RW34
PY04- SEMICONDUCTORS
D851
4822 130 82421 DIODE,1D3 1A/200V HD20002710
D858
D859 4822 130 81247 DIODE,1GWJ43 HD20031050
D860 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D861 4822 130 33057 DIODE,S2VB20 HE20011290
D862 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D863 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D864 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D865 4822 130 81157 ZENER,MTZJ3.0B HD30301000
D866 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D867 4822 130 82421 DIODE,1D3 1A/200V HD20002710
D868 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DM81
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DM93
DM94 /N/S 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DT01 4822 130 82421 DIODE,1D3 1A/200V HD20002710
Q851 4822 209 83317 IC,NJM7815FA +15V 1A HC38915090
Q852 4822 209 31864 IC,NJM7915FA HC39915090
Q853 4822 209 31631 IC,NJM7805FA +5V HC38905090
Q854 4822 209 63179 IC,NJM7905FA HC39905090
Q855 4822 209 31631 IC,NJM7805FA +5V HC38905090
Q856 3141 018 50260 IC,BA033T +3.3V 1A TYPE HC36J33210
Q857 4822 130 63635 TRS.2SC4793 O,Y HT347932A0
Q858 4822 130 63635 TRS.2SC4793 O,Y HT347932A0
Q901 /N/S 9965 000 06293 IC,LC72722 RDS DECODER HC10404030
Q902 /N/S 4822 130 41947 TRS.C2458,C1740S,C3199,ETC HT30001000
Q903 /N/S 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
Q904 /N/S 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
Q951 /N/S 4822 209 83631 IC,NJM4558D-D HC10008090
QM81 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QM82 5322 209 11532 IC,74HC4094 16PIN DIP HC709449B0
QM83
4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QM88
QM89 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QM90 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QT02 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QT03 /N 4822 209 70084 IC,NJM7812FA +12V HC38912090
QT03 /S/U IC,NJM7812FA +12V HC38912090
QT04 4822 130 61227 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QW01 4822 209 73064 IC,NJM-2068-DD HC10053090
QW31 4822 209 83631 IC,NJM4558D-D HC10008090
QY01 9965 000 12340 IC,TC74HC368AP HC736805B0
PY04- MISCELLANEOUS
F851 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F851 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
F852 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F852 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
F853 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F853 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
F854 /N/S 4822 071 52002 FUSE,T2.0A 250V TR5 FS20200200
F854 /U FUSE,T2A 250V TR5 NO.19374 FS20200210
L901 /N/S 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
L911 /N/S 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LT05 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LT06 4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
X901 /N/S 4822 242 10857 CRYSTAL,4.332MHZ,AT-49 JX04003260
