153
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P114- POWER AMP FL FR SBL
CIRCUIT BOARD
P114- CAPACITORS
C101 ELECT.22µF ±20% 25V ARS OA22602540
C102 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C103 ELECT.100µF ±20% 50V RA-2 OA10705020
C104 FILM,APSV 122J,
1200pF(TP) 100V PP
OF15122540
C105 ELECT.10µF ±20% 50V RA-2 OA10605020
C106 ELECT.220µF ±20% 100V RA-2 OA22710020
C107 ELECT.220µF ±20% 100V RA-2 OA22710020
C111 MICA,10pF D 250WV AUDIO DF31100520
C112 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C113 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C148 ELECT.100µF ±20% 25V RA-2 OA10702520
C149 ELECT.100µF ±20% 25V RA-2 OA10702520
C201 ELECT.22µF ±20% 25V ARS OA22602540
C202 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C203 ELECT.100µF ±20% 50V RA-2 OA10705020
C204 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C205 ELECT.10µF ±20% 50V RA-2 OA10605020
C206 ELECT.220µF ±20% 100V RA-2 OA22710020
C207 ELECT.220µF ±20% 100V RA-2 OA22710020
C211 MICA,10pF D 250WV AUDIO DF31100520
C212 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C301 ELECT.22µF ±20% 25V ARS OA22602540
C302 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C303 ELECT.100µF ±20% 50V RA-2 OA10705020
C304 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C305 ELECT.10µF ±20% 50V RA-2 OA10605020
C306 ELECT.220µF ±20% 100V RA-2 OA22710020
C307 ELECT.220µF ±20% 100V RA-2 OA22710020
C311 MICA,10pF D 250WV AUDIO DF31100520
C312 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C313 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C348 ELECT.100µF ±20% 25V RA-2 OA10702520
C349 ELECT.100µF ±20% 25V RA-2 OA10702520
C401 ELECT.22µF ±20% 25V ARS OA22602540
C402 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C403 ELECT.100µF ±20% 50V RA-2 OA10705020
C404 FILM,APSV 122J 1
200pF(TP) 100V PP
OF15122540
C406 ELECT.220µF ±20% 100V RA-2 OA22710020
C407 ELECT.220µF ±20% 100V RA-2 OA22710020
C411 MICA,10pF D 250WV AUDIO DF31100520
P114-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C108 C208 C308
P114- RESISTORS
R106
330
Ω ±5% 1/4W GG05331140
R109
R113 470
Ω ±5% 1/6W GG05471160
R114 470
Ω ±5% 1/6W GG05471160
R117 150
Ω ±5% 1/6W GG05151160
R118 150
Ω ±5% 1/6W GG05151160
R123 TRIM.VARI. 470 VERTICAL RA04710760
R124 100
Ω ±5% 1/6W GG05101160
R125 100
Ω ±5% 1/6W GG05101160
R126 1k
Ω ±5% 1/4W GG05102140
R127 47
Ω ±5% 1/4W GG05470140
R128 47
Ω ±5% 1/4W GG05470140
R129 10
Ω ±5% 1/4W GG05100140
R130 10
Ω ±5% 1/4W GG05100140
R131 220
Ω ±5% 1/4W GG05221140
R132 FIXED ,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R142 10
Ω ±5% 1/4W GG05100140
R143 10
Ω ±5% 1/4W GG05100140
R149 10
Ω ±5% 1/4W GG05100140
R206
330
Ω ±5% 1/4W GG05331140
R209
R213 470
Ω ±5% 1/6W GG05471160
R214 470
Ω ±5% 1/6W GG05471160
R217 150
Ω ±5% 1/6W GG05151160
R218 150
Ω ±5% 1/6W GG05151160
R223 TRIM.VARI. 470 VERTICAL RA04710760
R224 100
Ω ±5% 1/6W GG05101160
R225 100
Ω ±5% 1/6W GG05101160
R226 1k
Ω ±5% 1/4W GG05102140
R227 47
Ω ±5% 1/4W GG05470140
R228 47
Ω ±5% 1/4W GG05470140
R229 10
Ω ±5% 1/4W GG05100140
R230 10
Ω ±5% 1/4W GG05100140
R231 220
Ω ±5% 1/4W GG05221140
R232 FIXED ,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R242 10
Ω ±5% 1/4W GG05100140
R243 10
Ω ±5% 1/4W GG05100140
R306
330
Ω ±5% 1/4W GG05331140
R309
R313 470
Ω ±5% 1/6W GG05471160
R314 470
Ω ±5% 1/6W GG05471160
R317 150
Ω ±5% 1/6W GG05151160
R318 150
Ω ±5% 1/6W GG05151160
R323 TRIM.VARI. 470 VERTICAL RA04710760
R324 100
Ω ±5% 1/6W GG05101160
R325 100
Ω ±5% 1/6W GG05101160
R326 1k
Ω ±5% 1/4W GG05102140
R327 47
Ω ±5% 1/4W GG05470140
R328 47
Ω ±5% 1/4W GG05470140
R329 10
Ω ±5% 1/4W GG05100140
R330 10
Ω ±5% 1/4W GG05100140
R331 220
Ω ±5% 1/4W GG05221140
R332 FIXED ,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R342 10
Ω ±5% 1/4W GG05100140
R343 10
Ω ±5% 1/4W GG05100140
R406
330
Ω ±5% 1/4W GG05331140
R409
R413 470
Ω ±5% 1/6W GG05471160
R414 470
Ω ±5% 1/6W GG05471160
R417 150
Ω ±5% 1/6W GG05151160
