NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CN18 ELECT.1µF ±20% 50V RA-2 OA10505020
CN66 ELECT.1µF ±20% 50V RA-2 OA10505020
K101 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K102 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K103 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K201 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K202 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K203 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K301 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K302 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K303 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P124- SPKOUTS
FRONT SURRBACK HEAD
CIRCUIT BOARD
P124- CAPACITORS
CN10 CER.100pF UP050B101K-A DA16101110
CN11 CER.100pF UP050B101K-A DA16101110
CN12 CER.100pF UP050B101K-A DA16101110
P124-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C109 C110 C209
C210 C309 C310 C409 C410
P124- RESISTORS
R138 10
Ω ±5% 1W GA05100010
R238 10
Ω ±5% 1W GA05100010
R338 10
Ω ±5% 1W GA05100010
R438 10
Ω ±5% 1W GA05100010
RN35 330
Ω ±5% 1/4W GG05331140
RN37 330
Ω ±5% 1/4W GG05331140
RP91 330
Ω ±5% 1W GA05331010
RP92 330
Ω ±5% 1W GA05331010
RP93 330
Ω ±5% 1/4W GG05331140
P124- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN27-RN32
P124- SEMICONDUCTORS
DN05 DIODE,1D3 1A/200V HD20002710
DN07 DIODE,1D3 1A/200V HD20002710
DP91 DIODE,1D3 1A/200V HD20002710
QN04 TRS.2SC2458 Y OR GR HT324582B0
QN05 TRS.2SC2458 Y OR GR HT324582B0
QN06 TRS.2SC2458 Y OR GR HT324582B0
P124- MISCELLANEOUS
J149 TERMINAL,SPKROUT FL FR YT01040880
J349 TERMINAL,SPKROUT SBL SBR YT01040880
LN01 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN03 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LP91 RELAY,HP OUT RELAY LY20240490
P134- Q111
CIRCUIT BOARD
P134- SEMICONDUCTORS
Q111 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P154- POWER AMP C SL SR,
AVSS SENS
CIRCUIT BOARD
P154- CAPACITORS
C151 ELECT.22µF ±20% 25V ARS OA22602540
C152 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C153 ELECT.100µF ±20% 50V RA-2 OA10705020
C154 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C155 ELECT.10µF ±20% 50V RA-2 OA10605020
C156 ELECT.220µF ±20% 100V RA-2 OA22710020
C157 ELECT.220µF ±20% 100V RA-2 OA22710020
C161 MICA,10pF D 250WV AUDIO DF31100520
C162 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C163 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C198 ELECT.100µF ±20% 25V RA-2 OA10702520
C199 ELECT.100µF ±20% 25V RA-2 OA10702520
C213 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C251 ELECT.22µF ±20% 25V ARS OA22602540
C252 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C253 ELECT.100µF ±20% 50V RA-2 OA10705020
C254 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C255 ELECT.10µF ±20% 50V RA-2 OA10605020
C256 ELECT.220µF ±20% 100V RA-2 OA22710020
C257 ELECT.220µF ±20% 100V RA-2 OA22710020
C261 MICA,10pF D 250WV AUDIO DF31100520
C262 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C263 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C351 ELECT.22µF ±20% 25V ARS OA22602540
C352 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C353 ELECT.100µF ±20% 50V RA-2 OA10705020
C354 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C355 ELECT.10µF ±20% 50V RA-2 OA10605020
C356 ELECT.220µF ±20% 100V RA-2 OA22710020
C357 ELECT.220µF ±20% 100V RA-2 OA22710020
C361 MICA,10pF D 250WV AUDIO DF31100520
C362 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C363 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C389 ELECT.100µF ±20% 25V RA-2 OA10702520
C399 ELECT.100µF ±20% 25V RA-2 OA10702520
C501
CER.100pF UP050B101K-A DA16101110
C507
C508 ELECT.1µF ±20% 50V RA-2 OA10505020
C509 ELECT.100µF ±20% 25V RA-2 OA10702520
C510 ELECT.100µF ±20% 25V RA-2 OA10702520
CN01 ELECT.100µF ±20% 50V RA-2 OA10705020
CN02 CER.0.01µF Z 50V DK18103310
