Marantz SR9200 - Page 126

156
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CN03 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN04 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN05 ELECT.1µF ±20% 50V RA-2 OA10505020
CN06 CER.0.01µF Z 50V DK18103310
CN15 ELECT.10µF ±20% 50V RA-2 OA10605020
CN17 CER.0.01µF Z 50V DK18103310
CN61 ELECT.100µF ±20% 25V RA-2 OA10702520
CN62 CER.0.01µF Z 50V DK18103310
CN63 ELECT.1µF ±20% 50V RA-2 OA10505020
CN64 ELECT.1µF ±20% 50V RA-2 OA10505020
CN65 ELECT.1µF ±20% 50V RA-2 OA10505020
P154-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C158 C258 C358
P154- RESISTORS
R156
330
Ω ±5% 1/4W GG05331140
R159
R163 470
Ω ±5% 1/6W GG05471160
R164 470
Ω ±5% 1/6W GG05471160
R167 150
Ω ±5% 1/6W GG05151160
R168 150
Ω ±5% 1/6W GG05151160
R173 TRIM.VARI. 470 VERTICAL RA04710760
R174 100
Ω ±5% 1/6W GG05101160
R175 100
Ω ±5% 1/6W GG05101160
R176 1k
Ω ±5% 1/4W GG05102140
R177 47
Ω ±5% 1/4W GG05470140
R178 47
Ω ±5% 1/4W GG05470140
R179 10
Ω ±5% 1/4W GG05100140
R180 10
Ω ±5% 1/4W GG05100140
R181 220
Ω ±5% 1/4W GG05221140
R182 FIXED ,0.10
Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R192 10
Ω ±5% 1/4W GG05100140
R193 10
Ω ±5% 1/4W GG05100140
R199 10
Ω ±5% 1/4W GG05100140
R256
330
Ω ±5% 1/4W GG05331140
R259
R263 470
Ω ±5% 1/6W GG05471160
R264 470
Ω ±5% 1/6W GG05471160
R267 150
Ω ±5% 1/6W GG05151160
R268 150
Ω ±5% 1/6W GG05151160
R273 TRIM.VARI. 470 VERTICAL RA04710760
R274 100
Ω ±5% 1/6W GG05101160
R275 100
Ω ±5% 1/6W GG05101160
R276 1k
Ω ±5% 1/4W GG05102140
R277 47
Ω ±5% 1/4W GG05470140
R278 47
Ω ±5% 1/4W GG05470140
R279 10
Ω ±5% 1/4W GG05100140
R280 10
Ω ±5% 1/4W GG05100140
R281 220
Ω ±5% 1/4W GG05221140
R282 FIXED ,0.10
Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R292 10
Ω ±5% 1/4W GG05100140
R293 10
Ω ±5% 1/4W GG05100140
R356
330
Ω ±5% 1/4W GG05331140
R359
R363 470
Ω ±5% 1/6W GG05471160
R364 470
Ω ±5% 1/6W GG05471160
R367 150
Ω ±5% 1/6W GG05151160
R368 150
Ω ±5% 1/6W GG05151160
R373 TRIM.VARI. 470 VERTICAL RA04710760
R374 100
Ω ±5% 1/6W GG05101160
R375 100
Ω ±5% 1/6W GG05101160
R376 1k
Ω ±5% 1/4W GG05102140
R377 47
Ω ±5% 1/4W GG05470140
R378 47
Ω ±5% 1/4W GG05470140
R379 10
Ω ±5% 1/4W GG05100140
R380 10
Ω ±5% 1/4W GG05100140
R381 220
Ω ±5% 1/4W GG05221140
R382 FIXED ,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R392 10
Ω ±5% 1/4W GG05100140
R393 10
Ω ±5% 1/4W GG05100140
RN83 4.7
Ω ±5% 1/2W GG05047120
P154- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R151 R152 R154
R155 R160-R162 R165 R166
R169-R172 R183-R187 R189
R251 R252 R254 R255 R260
R261 R262 R265 R266 R269
R270 R271 R272 R283-R287
R289 R351 R352 R354 R355
R360 R361 R362 R365 R366
R369-R372 R383-R387 R389
R501-R509 R517 R530-R535
R540 R541 R545 R549
RN01-RN16 RN18-RN23 RN42
RN43 RN61 RN63-RN71 RN76
RN77 RN80 RN84 RN85
P154- SEMICONDUCTORS
D151
DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D154
D155 ZENER,8.2V EQUIVALENT HD30821000
D156 ZENER,8.2V EQUIVALENT HD30821000
D157 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D158 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D159 ZENER,4.3V EQUIVALENT HD30431000
D251
DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D254
D255 ZENER,8.2V EQUIVALENT HD30821000
D256 ZENER,8.2V EQUIVALENT HD30821000
D257 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D258 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D259 ZENER,4.3V EQUIVALENT HD30431000
D351
DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D354
D355 ZENER,8.2V EQUIVALENT HD30821000
D356 ZENER,8.2V EQUIVALENT HD30821000
D357 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D358 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
