NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
D359 ZENER,4.3V EQUIVALENT HD30431000
D511
DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D517
DN61 ZENER,8.2V EQUIVALENT HD30821000
DN62 ZENER,4.7V EQUIVALENT HD30471000
Q151 IC,NJM-2068-DD HC10053090
Q153 TRS.2SA1048 Y OR GR HT110482B0
Q154 TRS.2SC2458 Y OR GR HT324582B0
Q155 TRS.2SC2240 GR OR BL HT322402A0
Q156 TRS.2SA970 (GR) OR (BL) HT109702A0
Q157 TRS.2SA970 (GR) OR (BL) HT109702A0
Q158 TRS.2SC2240 GR OR BL HT322402A0
Q159 TRS.2SA1145 O OR Y TAPING HT111452A0
Q160 TRS.2SC2705 O OR Y TAPING HT327052A0
Q162 TRS.2SC4883 O OR Y HT348832A0
Q163 TRS.2SA1859 O OR Y HT118592A0
Q164 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q165 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q166 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q167 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q168 TRS.2SC2240 GR OR BL HT322402A0
Q253 TRS.2SA1048 Y OR GR HT110482B0
Q254 TRS.2SC2458 Y OR GR HT324582B0
Q255 TRS.2SC2240 GR OR BL HT322402A0
Q256 TRS.2SA970 (GR) OR (BL) HT109702A0
Q257 TRS.2SA970 (GR) OR (BL) HT109702A0
Q258 TRS.2SC2240 GR OR BL HT322402A0
Q259 TRS.2SA1145 O OR Y TAPING HT111452A0
Q260 TRS.2SC2705 O OR Y TAPING HT327052A0
Q262 TRS.2SC4883 O OR Y HT348832A0
Q263 TRS.2SA1859 O OR Y HT118592A0
Q264 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q265 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q266 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q267 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q268 TRS.2SC2240 GR OR BL HT322402A0
Q351 IC,NJM-2068-DD HC10053090
Q353 TRS.2SA1048 Y OR GR HT110482B0
Q354 TRS.2SC2458 Y OR GR HT324582B0
Q355 TRS.2SC2240 GR OR BL HT322402A0
Q356 TRS.2SA970 (GR) OR (BL) HT109702A0
Q357 TRS.2SA970 (GR) OR (BL) HT109702A0
Q358 TRS.2SC2240 GR OR BL HT322402A0
Q359 TRS.2SA1145 O OR Y TAPING HT111452A0
Q360 TRS.2SC2705 O OR Y TAPING HT327052A0
Q362 TRS.2SC4883 O OR Y HT348832A0
Q363 TRS.2SA1859 O OR Y HT118592A0
Q364 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q365 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q366 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q367 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q368 TRS.2SC2240 GR OR BL HT322402A0
Q501 IC,NJM2901
QUAD COMPARATOR
HC10009090
Q502 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN01 IC,TA7317P HC10042050
QN02 TRS.2SC2458 Y OR GR HT324582B0
QN03 TRS.2SC2458 Y OR GR HT324582B0
QN09 TRS.2SA970 (GR) OR (BL) HT109702A0
QN11 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN61 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN62 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN63 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN64 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P154- MISCELLANEOUS
K151 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K152 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K153 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K251 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K252 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K253 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K351 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K352 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K353 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P164- SPKOUTS SURR
CENTER MULTI
CIRCUIT BOARD
P164- CAPACITORS
CN13 CER.100pF UP050B101K-A DA16101110
P164-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C159 C160 C259
C260 C359 C360
P164- RESISTORS
R188 10
Ω ±5% 1W GA05100010
R288 10
Ω ±5% 1W GA05100010
R388 10
Ω ±5% 1W GA05100010
RN36 330
Ω ±5% 1/4W GG05331140
RN38 330
Ω ±5% 1/4W GG05331140
RN39 330
Ω ±5% 1/4W GG05331140
P164- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN33 RN34
P164- SEMICONDUCTORS
DN06 DIODE,1D3 1A/200V HD20002710
DN08 DIODE,1D3 1A/200V HD20002710
