Marantz SR9200 - Page 128

158
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
DN09 DIODE,1D3 1A/200V HD20002710
QN07 TRS.2SC2458 Y OR GR HT324582B0
P164- MISCELLANEOUS
J199 TERMINAL,SPKROUT
CENTER SL SR
YT01060030
J299 TERMINAL,SPKROUT ML MR YT01040880
LN02 RELAY, VB 24MBU-510
5A/240VAC
LY20240310
LN04 RELAY, VB 24MBU-510
5A/240VAC
LY20240310
LN05 RELAY, VB 24MBU-510
5A/240VAC
LY20240310
P174- Q161
CIRCUIT BOARD
P174- SEMICONDUCTORS
Q161 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P214- Q211
CIRCUIT BOARD
P214- SEMICONDUCTORS
Q211 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P254- Q261
CIRCUIT BOARD
P254- SEMICONDUCTORS
Q261 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P314- Q311
CIRCUIT BOARD
P314- SEMICONDUCTORS
Q311 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P354- Q361
CIRCUIT BOARD
P354- SEMICONDUCTORS
Q361 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P414- SBR POWER AMP
CIRCUIT BOARD
P414- CAPACITORS
C405 ELECT.10µF ±20% 50V RA-2 OA10605020
C412 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C413 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C414 ELECT,47µF/100V EA47610010
C415 ELECT,47µF/100V EA47610010
CN16 ELECT.10µF ±20% 50V RA-2 OA10605020
P414-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C408
P414- RESISTORS
R423 TRIM.470
Ω RH0638CS2R RA04710780
R424 100
Ω ±5% 1/6W GG05101160
R425 100
Ω ±5% 1/6W GG05101160
R426 1k
Ω ±5% 1/4W GG05102140
R427 47
Ω ±5% 1/4W GG05470140
R428 47
Ω ±5% 1/4W GG05470140
R429 10
Ω ±5% 1/4W GG05100140
R430 10
Ω ±5% 1/4W GG05100140
R431 220
Ω ±5% 1/4W GG05221140
R432 FIXED ,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
P414- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R421 R422 R433
R434 R435 R436 R437 R439
R548 RN44 RN45
P414- SEMICONDUCTORS
D403 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D404 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D405 ZENER,8.2V EQUIVALENT HD30821000
D406 ZENER,8.2V EQUIVALENT HD30821000
D407 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D408 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D409 ZENER,4.3V EQUIVALENT HD30431000
Q411 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q412 TRS.2SC4883 O OR Y HT348832A0
Q413 TRS.2SA1859 O OR Y HT118592A0
Q414 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q415 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q416 TRS. 2SC2922 O,Y HT329222A0
Q417 TRS. 2SA1216 O,Y HT112162A0
Q418 TRS.2SC2240 GR OR BL HT322402A0
QN10 TRS.2SA970 (GR) OR (BL) HT109702A0
P414- MISCELLANEOUS
K401 KIT,2SA1358 O,2SC3421 O HK135819A0
K402 KIT,2SA1216/2SC2922(O,Y)
PAIR
HK121619F0
K403 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P604- DSP AND µ-COM
CIRCUIT BOARD
P604- CAPACITORS
C610 CER.GRM39F104Z16 0.1µF DK98104200
C611 ELECT.47µF ±20% 16V RA-2 OA47601620
C612 CER.GRM39F104Z16 0.1µF DK98104200
C613 ELECT.47µF ±20% 16V RA-2 OA47601620
C614 CER.GRM39F104Z16 0.1µF DK98104200
C615 ELECT.47µF ±20% 16V RA-2 OA47601620
C616 CER.470pF (GR39) DK96471300
C617 CER.0.01µF DK98103300
C618 ELECT.2.2µF ±20% 50V RA-2 OA22505020
C619 CER.GRM39F104Z16 0.1µF DK98104200
C620 ELECT.47µF ±20% 16V RA-2 OA47601620
C621 CER.GRM39F104Z16 0.1µF DK98104200
C622 CER.GRM39F104Z16 0.1µF DK98104200
C640 CER.GRM39F104Z16 0.1µF DK98104200
C641 ELECT.47µF ±20% 16V RA-2 OA47601620
C642 CER.GRM39F104Z16 0.1µF DK98104200
C643 ELECT.47µF ±20% 16V RA-2 OA47601620
