NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P814- SEMICONDUCTORS
D801 DIODE,1D3 1A/200V HD20002710
D802 DIODE,1D3 1A/200V HD20002710
D803 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D804 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D811
DIODE, 1D3 1A/200V HD20002710
D816
D817 ZENER,5.1V EQUIVALENT HD30511000
Q801 TRS.2SA1048 Y OR GR HT110482B0
Q802 TRS.2SA1048 Y OR GR HT110482B0
Q803 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
Q811 IC, NJM78M05FA HC38505090
Q812 IC,PST600D-2 RESET TAPING HC10098550
P814- MISCELLANEOUS
F801 FUSE, 12A 250V
UL,CSA,MITI NO.314
FS11200440
J801 JACK, 2P AC OUTLET
(CCT1304-0212)
YJ04002040
L801 RELAY, VS24MB-NR TV-8 LY10240240
L802 POWER RELAY,G5PA-1 5A LY10120400
L811 POWER TRANSF. AC100V TS13521090
P824- POWER SW
(EXEPT U)
CIRCUIT BOARD
P824- CAPACITORS
C801 CER. DE1307-1E 472M-KH DK17472910
P824- MISCELLANEOUS
S801 PUSH SW. MAINS POWER
ESB92S17B
SP01013800
P834- POWER SUPPLY
FOR POWER AMP
CIRCUIT BOARD
P834- CAPACITORS
C511 CER.100pF UP050B101K-A DA16101110
C514 ELECT,47µF/16V EJ47601610
C831 ELECT.ELNA RA2 16X25 OA10805020
C832 ELECT.470µF ±20% 50V RA-2 OA47705020
C833
CER.50V DC 0.1µF +80-20% DD38104010
C836
C837 ELECT.100µF ±20% 25V RA-2 OA10702520
C838 ELECT.100µF ±20% 25V RA-2 OA10702520
C839 ELECT.100µF ±20% 50V RA-2 OA10705020
C840 CER.50V DC 0.1µF +80-20% DD38104010
C841 CER.50V DC 0.1µF +80-20% DD38104010
C842
ELECT.35XL90 VNSD OB18907120
C845
C846 CER.50V DC 0.1µF +80-20% DD38104010
C847 ELECT.100µF ±20% 25V RA-2 OA10702520
C848 CER.50V DC 0.1µF +80-20% DD38104010
CN07 ELECT. 220µF ±20% 50V RA-2 OA22705020
CN08 CER.100pF UP050B101K-A DA16101110
CN09 CER.100pF UP050B101K-A DA16101110
P834-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C512
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
C513
P834- RESISTORS
R538 330
Ω ±5% 1/4W GG05331140
R539 330
Ω ±5% 1/4W GG05331140
R831 100
Ω ±5% 1/4W GG05101140
R832 100
Ω ±5% 1/4W GG05101140
R833 1
Ω ±5% 1/2W GG05010120
R834 1
Ω ±5% 1/4W GG05010140
R835 100
Ω ±5% 1/6W GG05101160
RN24 1
Ω ±5% 1/4W GG05010140
P834- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R536 R537
R551-R563 RN25 RN26 RN46
P834- SEMICONDUCTORS
D501 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D502 DIODE,1D3 1A/200V HD20002710
D503 DIODE,1D3 1A/200V HD20002710
D831
DIODE,1D3 1A/200V HD20002710
D838
D839 ZENER,MTZJ33D HD33301000
D840 ZENER,6.8V EQUIVALENT HD30681000
D841 DIODE, 600V 25A
BRIDGE-DI D25XB60
HE20029290
DN01 DIODE, 1D3 1A/200V HD20002710
DN02 DIODE, 1D3 1A/200V HD20002710
DN03 ZENER,MTZJ2.0B HD30201000
DN04 ZENER,MTZJ2.0B HD30201000
Q503 TRS.2SC2458 Y OR GR HT324582B0
Q504 TRS.2SC2458 Y OR GR HT324582B0
Q505 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
Q506 TRS.2SC2458 Y OR GR HT324582B0
Q507 TRS.2SC2458 Y OR GR HT324582B0
Q508 TRS.2SA1048 Y OR GR HT110482B0
Q831 IC, NJM78M18FA HC38518090
Q832 IC, -18V 500MA REG.
NJM79M18FA JR
HC39518090
Q833 IC, NJM78M18FA HC38518090
P834- MISCELLANEOUS
L501 RELAY, VSB24STB 16A AVSS LY10240300
L502 RELAY, VSB24STB 16A AVSS LY10240300
P844- AC INLET
CIRCUIT BOARD
P844- MISCELLANEOUS
J810 JACK, 2P MAINS INLET
PWI1910-H
YJ04002440
