Marantz SR9200 - Page 133

163
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PC04- FRONT
CIRCUIT BOARD
PC04- CAPACITORS
CC01
CER.50V DC 0.1µF +80-20% DD38104010
CC05
CC07 CER.390pF DA16391110
CC08 CER.100pF UP050B101K-A DA16101110
CC09 CER.CER. 0.1µF Z 50V DA17104110
CC10 CER.CER. 0.1µF Z 50V DA17104110
CC11 CER.CER. 0.1µF Z 50V DA17104110
CC12 CER.50V DC 0.1µF +80-20% DD38104010
CC13 CER.CER. 0.1µF Z 50V DA17104110
CC16 CER.50V DC 0.1µF +80-20% DD38104010
CC17 CER.0.022µF Z 50V DK18223310
CC18 ELECT,47µF/6.3V EJ47600610
CC21 CER.50V DC 0.1µF +80-20% DD38104010
CC22 CER.50V DC 0.1µF +80-20% DD38104010
CC30 ELECT,10µF/50V EJ10605010
CC31 CER.CER. 0.1µF Z 50V DA17104110
CC32 CER.CER. 0.1µF Z 50V DA17104110
CC33 CER.CER. 0.1µF Z 50V DA17104110
CC34 ELECT,10µF/16V EJ10601610
CC35 CER.50V DC 0.1µF +80-20% DD38104010
CC36 ELECT,100µF/6.3V EJ10700610
CC38 CER.50V DC 0.1µF +80-20% DD38104010
CC40 CER.10000pF DA17103110
CC41 CER.10000pF DA17103110
CC43 ELECT,100µF/6.3V EJ10700610
CC44 CER.50V DC 0.1µF +80-20% DD38104010
CC50 ELECT.100µF ±20% 10V RA-2 OA10701020
CC51 ELECT.100µF ±20% 50V RA-2 OA10705020
PC04-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : CC20
PC04- RESISTORS
RC08 COMPO.RKC13BS473J
±5% P1.8
BW05473230
RC09 COMPO.RKC13BS473J
±5% P1.8
BW05473230
RC10 COMPO.RKC13BS103J
±5% P1.8
BW05103330
RC11 COMPO.RKC13BS473J
±5% P1.8
BW05473230
PC04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RC01-RC04 RC06
RC12 RC13 RC17-RC21
RC24-RC50 RC52
PC04- SEMICONDUCTORS
DC01 L.E.D.GL3ED8 SHARP HI10099320
DC02
L.E.D.SLR-932AV-8K A RANK
5MM P2.5
HI20006030
DC05
DC06 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
QC01 IC,NJM3430FG1 HC10220090
QC02 TRS.C2458,C1740S,C3199,ETC HT30001000
QC03 TRS.C2458,C1740S,C3199,ETC HT30001000
QC04 PHOTO UNIT,
IR SENSOR TSOP 1136 TB1
HW10002620
QC05 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC06 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC07 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QC08 TRS.C2458,C1740S,C3199,ETC HT30001000
QC09 TRS.2SC2120 O HT321201A0
QC10 TRS.2SC2120 O HT321201A0
QC11 IC,PST600D-2 RESET TAPING HC10098550
PC04- MISCELLANEOUS
SC01
PUSH SW.EVQ11L05R H/5MM,
160GF
SP01013370
SC26
SC27 ROTALY ENCODER,
EC16B 16PLS 16CLICK
SR02010080
VC01 DISPLAY UNIT,16-BT-92GNK HQ31601410
PC74- UP/DOWN SW
CIRCUIT BOARD
PC74- MISCELLANEOUS
SC70 PUSH SW.EVQ11L05R
H/5MM,160GF
SP01013370
SC71 PUSH SW.EVQ11L05R
H/5MM,160GF
SP01013370
PC84- VOLUME ENCODER
CIRCUIT BOARD
PC84- CAPACITORS
CC80 CER.50V DC 0.1µF +80-20% DD38104010
CC81 CER.10000pF DA17103110
CC82 CER.10000pF DA17103110
PC84- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RC80-RC85
PC84- MISCELLANEOUS
SC80 PUSH SW.EVQ11L05R H/5MM,
160GF
SP01013370
SC81 PUSH SW.EVQ11L05R H/5MM,
160GF
SP01013370
SC82 ROTALY ENCODER,
36PULSE EC16B
SR02010070
PD04- DIG IN/ADC/DAC
CIRCUIT BOARD
PD04- CAPACITORS
CA01
CER.0.1µF ±10% B 10V DK96104200
CA05
CA06
CER.GRM39F104Z16 0.1µF DK98104200
CA09
CA10 ELECT.47µF ±20% 25V RA-2 OA47602520
CA12 ELECT.47µF ±20% 25V RA-2 OA47602520
CA14
CER.GRM39F104Z16 0.1µF DK98104200
CA20
