Marantz SR9200 - Page 136

166
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RK23
CHIP,22k
Ω ±5% 1/16W NN05223610
RK28
RK29 CHIP,47k
Ω ±5% 1/16W NN05473610
RK30 CHIP,47k
Ω ±5% 1/16W NN05473610
RK31 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK32 CHIP,47k
Ω ±5% 1/16W NN05473610
RK33 CHIP,10k
Ω ±5% 1/16W NN05103610
RK34 CHIP,5.6k
Ω ±5% 1/16W NN05562610
RK35 CHIP,10k
Ω ±5% 1/16W NN05103610
RK36 CHIP,5.6k
Ω ±5% 1/16W NN05562610
RK37 CHIP,10k
Ω ±5% 1/16W NN05103610
RK39 CHIP,680k
Ω ±5% 1/16W NN05684610
RK40 CHIP,680k
Ω ±5% 1/16W NN05684610
RK41 CHIP,680k
Ω ±5% 1/16W NN05684610
RK42 CHIP,47k
Ω ±5% 1/16W NN05473610
RK43 CHIP,680k
Ω ±5% 1/16W NN05684610
RK44 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK46 CHIP,10k
Ω ±5% 1/16W NN05103610
RK47 CHIP,10k
Ω ±5% 1/16W NN05103610
RK48 CHIP,10k
Ω ±5% 1/16W NN05103610
RK49 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RK50 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RK51 CHIP,10k
Ω ±5% 1/16W NN05103610
RK58 CHIP,470
Ω ±5% 1/16W NN05471610
RK70
CHIP,10k
Ω ±5% 1/16W NN05103610
RK73
RK74 680
Ω ±5% 1/6W GG05681160
RK75 680
Ω ±5% 1/6W GG05681160
RK76 CHIP,10k
Ω ±5% 1/16W NN05103610
RK77 CHIP,10k
Ω ±5% 1/16W NN05103610
PD04- SEMICONDUCTORS
DA01
CHIP DIODE,1SS302 HZ20018050
DA05
DK01
CHIP DIODE,1SS302 HZ20018050
DK05
DK70 CHIP DIODE,1SS302 HZ20018050
DK71 CHIP DIODE,1SS302 HZ20018050
QA01 IC,CMOS 74HCU04 FLAT
TAPING
HC700400Z0
QA02 IC,CMOS 74HCU04 FLAT
TAPING
HC700400Z0
QA03 IC,TC74HC151AF HC715100Z0
QA04 IC,TC74HC151AF HC715100Z0
QA05 IC,OR-GATE 74HC32 HC703200Z0
QA06 IC,CMOS 74HC00 FLAT
TAPING
HC700000Z0
QA07 IC,PCF8574I(I/O EXPANDER) HC10068490
QD01
IC,24BIT 192KHZ DAC
DR=120DB
HC10011880
QD04
QH01
IC,NJM2068M TAPING HC10102090
QH05
QJ01
IC,NJM2068M TAPING HC10102090
QJ04
QK01 CHIP TR. (2SC),2SC4213 HX342132A0
QK02 CHIP TR. (2SC),2SC4213 HX342132A0
QK03 IC,NJM2115M HC10172090
QK04 IC,NJM2115M HC10172090
QK05 IC,NJM2068M TAPING HC10102090
QK06 IC,NJM2068M TAPING HC10102090
QK07 DIG.TRS.DTA114EU BA10026210
QK08 IC,NJM2115M HC10172090
QK51 IC,ADC AK5383VS 96kHz 24BIT HC10033480
QK70 DIG.TRS.DTA114EU BA10026210
QK71 TRS.2SC2120 O HT321201A0
QK72 DIG.TRS.DTA114EU BA10026210
QK73 TRS.2SC2120 O HT321201A0
PD04- MISCELLANEOUS
JA01 TERMINAL,14X14 RA 1L3P BLK
AU F-SHIELD
YT02030610
JA02 TERMINAL,CINCH 2P AU(BL)
FRONT SHIELDED
YT02021540
JA03
OPT. CONNECTOR,JFJ400 YJ15000200
JA06
LD01
EMI FILTER,DSS306-91-F-223Z FM12223010
LD04
LK70 RELAY,MR82-24USR LY20240480
LK71 RELAY,MR82-24USR LY20240480
PF14- COMPONENT
CIRCUIT BOARD
PF14- CAPACITORS
CF61 CER.0.01µF Z 50V DK18103310
CF62 ELECT.10µF ±20% 50V RA-2 OA10605020
CF63 ELECT.470µF ±20% 6.3V RA-2 OA47700620
PF14- RESISTORS
RF53 1
Ω ±5% 1/6W GG05010160
RF59 1
Ω ±5% 1/6W GG05010160
RF76 1
Ω ±5% 1/6W GG05010160
RF77 75
Ω ±5% 1/6W GD05750160
PF14- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RF51-RF52
RF57-RF58 RF74-RF75
PF14- SEMICONDUCTORS
DF51 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DF53 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DF54 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
QF51 TRS.2SC2458 Y OR GR HT324582B0
QF53 TRS.2SC2458 Y OR GR HT324582B0
QF54 TRS.2SC2458 Y OR GR HT324582B0
PF14- MISCELLANEOUS
JF51 TERMINAL,YKC21-4076 1L3
FS AU
YT02030700
JF52 TERMINAL,3P CINCH JACK
1L3 R/G/B GOLD
YT02030540
JF53 TERMINAL,3P CINCH JACK
1L3 R/G/B GOLD
YT02030540
LF51 RELAY,MR82-24USR LY20240480
LF52 RELAY,MR82-24USR LY20240480
LF53 RELAY,MR82-24USR LY20240480
