Marantz SR9200 - Page 137

167
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
LF56 RELAY,MR82-24USR LY20240480
LF57 RELAY,MR82-24USR LY20240480
LF58 RELAY,MR82-24USR LY20240480
LF59 RELAY,MR82-24USR LY20240480
PF24- D-TERMINAL
CIRCUIT BOARD
PF24- CAPACITORS
CF87 CER.0.01µF Z 50V DK18103310
CF88 ELECT.10µF ±20% 50V RA-2 OA10605020
CF91 CER.0.01µF Z 50V DK18103310
CF92 ELECT.10µF ±20% 50V RA-2 OA10605020
PF24- SEMICONDUCTORS
QF91 IC,C-MOS 74HC4053 HC705300B0
PF24- MISCELLANEOUS
JF91 JACK,YKF45-300T
D CONNECTOR ANGLE
YJ11000660
JF92 JACK,YKF45-300T
D CONNECTOR ANGLE
YJ11000660
JF93 JACK,YKF45-300T
D CONNECTOR ANGLE
YJ11000660
PG04- ELE.VOLUME
CIRCUIT BOARD
PG04- CAPACITORS
CE01 ELECT.22µF ±20% 50V RA-2 OA22605020
CE02 ELECT.22µF ±20% 50V RA-2 OA22605020
CE03 ELECT.10µF ±20% 50V RA-2 OA10605020
CE04 ELECT.10µF ±20% 50V RA-2 OA10605020
CE05 FILM,100pF ±5% 100V APSV OF15101540
CE06 FILM,100pF ±5% 100V APSV OF15101540
CE07 CER.50V DC 0.1µF +80-20% DD38104010
CE08 CER.50V DC 0.1µF +80-20% DD38104010
CE09 ELECT.22µF ±20% 50V RA-2 OA22605020
CE10 ELECT.22µF ±20% 50V RA-2 OA22605020
CE11 ELECT.22µF ±20% 25V ARS OA22602540
CE12 ELECT.22µF ±20% 25V ARS OA22602540
CE13 ELECT.10µF ±20% 50V RA-2 OA10605020
CE14 ELECT.10µF ±20% 50V RA-2 OA10605020
CE15 FILM,100pF ±5% 100V APSV OF15101540
CE16 FILM,100pF ±5% 100V APSV OF15101540
CE17 CER.50V DC 0.1µF +80-20% DD38104010
CE18 CER.50V DC 0.1µF +80-20% DD38104010
CE19 ELECT.47µF ±20% 25V RA-2 OA47602520
CE20 ELECT.47µF ±20% 25V RA-2 OA47602520
CE21 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CE22 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CE41 ELECT.47µF ±20% 25V RA-2 OA47602520
CE42 CER.50V DC 0.1µF +80-20% DD38104010
CE43 ELECT.47µF ±20% 25V RA-2 OA47602520
CE44 CER.50V DC 0.1µF +80-20% DD38104010
CE49 ELECT.100µF ±20% 16V RA-2 OA10701620
CE50 ELECT.100µF ±20% 16V RA-2 OA10701620
CE51 ELECT.22µF ±20% 50V RA-2 OA22605020
CE52 ELECT.22µF ±20% 50V RA-2 OA22605020
CE53 ELECT.10µF ±20% 50V RA-2 OA10605020
CE54 ELECT.10µF ±20% 50V RA-2 OA10605020
CE55 FILM,100pF ±5% 100V APSV OF15101540
CE57 CER.50V DC 0.1µF +80-20% DD38104010
CE58 CER.50V DC 0.1µF +80-20% DD38104010
CE59 ELECT.22µF ±20% 50V RA-2 OA22605020
CE60 ELECT.22µF ±20% 50V RA-2 OA22605020
CE61 ELECT.22µF ±20% 25V ARS OA22602540
CE62 ELECT.22µF ±20% 50V RA-2 OA22605020
CE63 ELECT.10µF ±20% 50V RA-2 OA10605020
CE64 ELECT.47µF ±20% 25V RA-2 OA47602520
CE65 FILM,100pF ±5% 100V APSV OF15101540
CE67 CER.50V DC 0.1µF +80-20% DD38104010
CE68 CER.50V DC 0.1µF +80-20% DD38104010
CE69 ELECT.47µF ±20% 25V RA-2 OA47602520
CE70 ELECT.47µF ±20% 25V RA-2 OA47602520
CE71 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CE91 ELECT.47µF ±20% 25V RA-2 OA47602520
CE92 CER.50V DC 0.1µF +80-20% DD38104010
CE93 ELECT.47µF ±20% 25V RA-2 OA47602520
CE94 CER.50V DC 0.1µF +80-20% DD38104010
CG01 ELECT.22µF ±20% 50V RA-2 OA22605020
CG02 ELECT.22µF ±20% 50V RA-2 OA22605020
CG03 ELECT.10µF ±20% 50V RA-2 OA10605020
CG04 ELECT.10µF ±20% 50V RA-2 OA10605020
CG05 FILM,100pF ±5% 100V APSV OF15101540
CG06 FILM,100pF ±5% 100V APSV OF15101540
CG07 CER.50V DC 0.1µF +80-20% DD38104010
CG08 CER.50V DC 0.1µF +80-20% DD38104010
CG09 ELECT.22µF ±20% 50V RA-2 OA22605020
CG10 ELECT.22µF ±20% 50V RA-2 OA22605020
CG11 ELECT.22µF ±20% 25V ARS OA22602540
CG12 ELECT.22µF ±20% 25V ARS OA22602540
CG13 ELECT.10µF ±20% 50V RA-2 OA10605020
CG14 ELECT.10µF ±20% 50V RA-2 OA10605020
CG15 FILM,100pF ±5% 100V APSV OF15101540
CG16 FILM,100pF ±5% 100V APSV OF15101540
CG17 CER.50V DC 0.1µF +80-20% DD38104010
CG18 CER.50V DC 0.1µF +80-20% DD38104010
CG19 ELECT.47µF ±20% 25V RA-2 OA47602520
CG20 ELECT.47µF ±20% 25V RA-2 OA47602520
CG21 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG22 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CG41 ELECT.47µF ±20% 25V RA-2 OA47602520
CG42 CER.50V DC 0.1µF +80-20% DD38104010
CG43 ELECT.47µF ±20% 25V RA-2 OA47602520
CG44 CER.50V DC 0.1µF +80-20% DD38104010
CG51 ELECT.22µF ±20% 50V RA-2 OA22605020
CG52 ELECT.22µF ±20% 50V RA-2 OA22605020
CG53 ELECT.10µF ±20% 50V RA-2 OA10605020
CG54 ELECT.10µF ±20% 50V RA-2 OA10605020
CG55 FILM,100pF ±5% 100V APSV OF15101540
CG56 FILM,100pF ±5% 100V APSV OF15101540
CG57 CER.50V DC 0.1µF +80-20% DD38104010
CG58 CER.50V DC 0.1µF +80-20% DD38104010
CG59 ELECT.22µF ±20% 50V RA-2 OA22605020
CG60 ELECT.22µF ±20% 50V RA-2 OA22605020
CG61 ELECT.22µF ±20% 25V ARS OA22602540
CG62 ELECT.22µF ±20% 25V ARS OA22602540
CG63 ELECT.10µF ±20% 50V RA-2 OA10605020
CG64 ELECT.10µF ±20% 50V RA-2 OA10605020
CG65 FILM,100pF ±5% 100V APSV OF15101540
CG66 FILM,100pF ±5% 100V APSV OF15101540
CG67 CER.50V DC 0.1µF +80-20% DD38104010
CG68 CER.50V DC 0.1µF +80-20% DD38104010
CG69 ELECT.47µF ±20% 25V RA-2 OA47602520
