Marantz SR9200 - Page 140

170
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
JE04 TERMINAL,14X14 RA 2L6P BLK
AU F-SHIELD
YT02060690
JE10 RETAINER,GND TERMINAL 320J104010
LE01 RELAY,MR82-24USR LY20240480
LE51 RELAY,MR82-24USR LY20240480
LG01 RELAY,MR82-24USR LY20240480
LG51 RELAY,MR82-24USR LY20240480
LM01 RELAY,MR82-24USR LY20240480
LM60 RELAY,MR82-24USR LY20240480
PL04- CVBS
CIRCUIT BOARD
PL04- CAPACITORS
CF01 ELECT.10µF ±20% 50V RA-2 OA10605020
CF02 ELECT.10µF ±20% 50V RA-2 OA10605020
CF03 ELECT.10µF ±20% 50V RA-2 OA10605020
CF04 CER.50V DC 0.1µF +80-20% DD38104010
CF05 ELECT.10µF ±20% 50V RA-2 OA10605020
CF06 ELECT.10µF ±20% 50V RA-2 OA10605020
CF07 ELECT.100µF ±20% 10V RA-2 OA10701020
CF08 CER.50V DC 0.1µF +80-20% DD38104010
CF09
ELECT.10µF ±20% 50V RA-2 OA10605020
CF13
CF14 CER.47pF ±5% CH 50V BLK DD15470300
CF15 CER.47pF ±5% CH 50V BLK DD15470300
CF16 ELECT.100µF ±20% 10V RA-2 OA10701020
CF17 CER.50V DC 0.1µF +80-20% DD38104010
CF19 CER.47pF ±5% CH 50V BLK DD15470300
CF20 ELECT.10µF ±20% 50V RA-2 OA10605020
CF21 ELECT.10µF ±20% 50V RA-2 OA10605020
CF22 CER.50V DC 0.1µF +80-20% DD38104010
CF23 ELECT.100µF ±20% 16V RA-2 OA10701620
CF24 ELECT.1µF ±20% 50V RA-2 OA10505020
CF26 CER.50V DC 0.1µF +80-20% DD38104010
CF27 CER.47pF ±5% CH 50V BLK DD15470300
CF28 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CF31 CER.50V DC 0.1µF +80-20% DD38104010
CF33 CER.50V DC 0.1µF +80-20% DD38104010
CL01 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL02 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL09
CER.47pF ±5% CH 50V BLK DD15470300
CL12
CL13 ELECT.10µF ±20% 50V RA-2 OA10605020
CL14 ELECT.10µF ±20% 50V RA-2 OA10605020
CL15 CER.50V DC 0.1µF +80-20% DD38104010
CL16
ELECT.10µF ±20% 50V RA-2 OA10605020
CL20
CL21 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL22 ELECT.10µF ±20% 50V RA-2 OA10605020
CL23 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL24 ELECT.100µF ±20% 10V RA-2 OA10701020
CL25 CER.50V DC 0.1µF +80-20% DD38104010
CL26 ELECT.100µF ±20% 10V RA-2 OA10701020
CL27 CER.50V DC 0.1µF +80-20% DD38104010
CL28 ELECT.10µF ±20% 50V RA-2 OA10605020
CL29 ELECT.10µF ±20% 50V RA-2 OA10605020
CL32 ELECT.10µF ±20% 50V RA-2 OA10605020
CL34 ELECT.10µF ±20% 50V RA-2 OA10605020
CL35 CER.50V DC 0.1µF +80-20% DD38104010
CL36 ELECT.10µF ±20% 50V RA-2 OA10605020
CL37 ELECT.2.2µF ±20% 50V RA-2 OA22505020
CL38 ELECT.10µF ±20% 50V RA-2 OA10605020
CL39 CER.24pF ±5% CH 50V BLK DD15240300
CL40 CER.22pF ±5% CH 50V BLK DD15220300
CL42 CER.50V DC 0.1µF +80-20% DD38104010
CL44 ELECT.1µF ±20% 50V RA-2 OA10505020
CL45 ELECT.1µF ±20% 50V RA-2 OA10505020
CL46 CER.50V DC 0.1µF +80-20% DD38104010
CL47 ELECT.10µF ±20% 50V RA-2 OA10605020
CL48 CER.22pF ±5% CH 50V BLK DD15220300
CL49 CER.22pF ±5% CH 50V BLK DD15220300
CL50 CER.47pF ±5% CH 50V BLK DD15470300
CL51 ELECT.10µF ±20% 50V RA-2 OA10605020
CL52 ELECT.10µF ±20% 50V RA-2 OA10605020
CL53 ELECT.100µF ±20% 10V RA-2 OA10701020
CL54 CER.50V DC 0.1µF +80-20% DD38104010
CL55 ELECT.1µF ±20% 50V RA-2 OA10505020
CL57 CER.50V DC 0.1µF +80-20% DD38104010
CL58 ELECT.100µF ±20% 16V RA-2 OA10701620
CL59 CER.47pF ±5% CH 50V BLK DD15470300
CL60 ELECT.100µF ±20% 10V RA-2 OA10701020
CL63 CER.50V DC 0.1µF +80-20% DD38104010
CL64 CER.0.01µF DC50V +80%-20% DD38103010
CL65 ELECT.10µF ±20% 50V RA-2 OA10605020
CL66 CER.0.01µF DC50V +80%-20% DD38103010
CL67 CER.0.01µF DC50V +80%-20% DD38103010
CL68 ELECT.10µF ±20% 50V RA-2 OA10605020
CL69 CER.0.01µF DC50V +80%-20% DD38103010
CL70 CER.0.01µF DC50V +80%-20% DD38103010
CL71 ELECT.10µF ±20% 50V RA-2 OA10605020
CL72 CER.0.01µF DC50V +80%-20% DD38103010
CL73 CER.0.022µF Z 50V DK18223310
CL78 CER.50V DC 0.1µF +80-20% DD38104010
CL79 ELECT.10µF ±20% 50V RA-2 OA10605020
CL80 ELECT.10µF ±20% 50V RA-2 OA10605020
CL81 ELECT.10µF ±20% 50V RA-2 OA10605020
CL82 CER.47pF ±5% CH 50V BLK DD15470300
CL85 CER.47pF ±5% CH 50V BLK DD15470300
CL87 ELECT.100µF ±20% 10V RA-2 OA10701020
PL04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CF25 CL43 CL62 CL83 CL86
PL04- RESISTORS
RF01 CHIP,75
Ω ±5% 1/10W NI05750110
RF02 CHIP,1k
Ω ±5% 1/10W NI05102110
RF03 CHIP,75
Ω ±5% 1/10W NI05102110
RF04 CHIP,10k
Ω ±5% 1/10W NI05103110
RF05 CHIP,75
Ω ±5% 1/10W NI05750110
RF06 CHIP,1M
Ω ±5% 1/10W NI05105110
RF07 CHIP,1M
Ω ±5% 1/10W NI05105110
RF08 CHIP,0
Ω ±5% 1/10W NI05000110
RF09
CHIP,1k
Ω ±5% 1/10W NI05102110
RF16
RL01 CHIP,75
Ω ±5% 1/10W NI05750110
RL02 CHIP,75
Ω ±5% 1/10W NI05750110
RL03 CHIP,75
Ω ±5% 1/10W NI05750110
RL04 CHIP,0
Ω ±5% 1/10W NI05000110
RL05 CHIP,75
Ω ±5% 1/10W NI05750110
RL06 CHIP,0
Ω ±5% 1/10W NI05000110
RL07 CHIP,75
Ω ±5% 1/10W NI05750110
RL08 CHIP,0
Ω ±5% 1/10W NI05000110
