NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RL09 CHIP,75 Ω ±5% 1/10W NI05750110
RL10 CHIP,0
Ω ±5% 1/10W NI05000110
RL11 CHIP,75
Ω ±5% 1/10W NI05750110
RL12 CHIP,0
Ω ±5% 1/10W NI05000110
RL13 CHIP,75
Ω ±5% 1/10W NI05750110
RL14 CHIP,0
Ω ±5% 1/10W NI05000110
RL15 CHIP,75
Ω ±5% 1/10W NI05750110
RL16 CHIP,75
Ω ±5% 1/10W NI05750110
RL18 CHIP,10k
Ω ±5% 1/10W NI05103110
RL19 CHIP,10k
Ω ±5% 1/10W NI05103110
RL20 CHIP,10k
Ω ±5% 1/10W NI05103110
RL21 CHIP,1k
Ω ±5% 1/10W NI05102110
RL22 CHIP,1k
Ω ±5% 1/10W NI05102110
RL23 CHIP,1k
Ω ±5% 1/10W NI05102110
RL24 CHIP,470
Ω ±5% 1/10W NI05471110
RL25 CHIP,10k
Ω ±5% 1/10W NI05103110
RL26 CHIP,100k
Ω ±5% 1/10W NI05104110
RL27 CHIP,10k
Ω ±5% 1/10W NI05103110
RL28 CHIP,12k
Ω ±5% 1/10W NI05123110
RL29 CHIP,220
Ω ±5% 1/10W NI05221110
RL30 CHIP,0
Ω ±5% 1/10W NI05000110
RL31 CHIP,1M
Ω ±5% 1/10W NI05105110
RL32 CHIP,0
Ω ±5% 1/10W NI05000110
RL33 CHIP,220
Ω ±5% 1/10W NI05221110
RL35 CHIP,10k
Ω ±5% 1/10W NI05103110
RL36 220
Ω ±5% 1/2W GG05221120
RL37 CHIP,4.7k
Ω ±5% 1/10W NI05472110
RL38 CHIP,10k
Ω ±5% 1/10W NI05103110
RL39 CHIP,1k
Ω ±5% 1/10W NI05102110
RL40 CHIP,56
Ω ±5% 1/10W NI05560110
RL41 CHIP,1k
Ω ±5% 1/10W NI05102110
RL42 CHIP,10k
Ω ±5% 1/10W NI05103110
RL43 CHIP,1k
Ω ±5% 1/10W NI05102110
RL44 CHIP,100
Ω ±5% 1/10W NI05101110
RL45 CHIP,100
Ω ±5% 1/10W NI05101110
RL57 CHIP,10k
Ω ±5% 1/10W NI05103110
RL58
CHIP,0
Ω ±5% 1/10W NI05000110
RL61
RL62 CHIP,75
Ω ±5% 1/10W NI05750110
RL63 CHIP,1M
Ω ±5% 1/10W NI05105110
RL64 CHIP,1M
Ω ±5% 1/10W NI05105110
RL68 CHIP,0
Ω ±5% 1/10W NI05000110
RL69 CHIP,75
Ω ±5% 1/10W NI05750110
RL70 CHIP,0
Ω ±5% 1/10W NI05000110
RL72
CHIP,1k
Ω ±5% 1/10W NI05102110
RL84
RL85 CHIP,0
Ω ±5% 1/10W NI05000110
PL04- SEMICONDUCTORS
DL01 CHIP DIODE,DAN202K HZ20002210
QF01 IC,NJM2534M TAPING TE1 HC10223090
QF02 IC,NJM2296M TAPING HC10210090
QF03 IC,NJM2535M TAPING TE1 HC10224090
QF04 IC,74HC4094 16PIN DIP HC709449B0
QL01 IC,NJM2534M TAPING TE1 HC10223090
QL02 IC,NJM2296M TAPING HC10210090
QL03 IC,NJM2535M TAPING TE1 HC10224090
QL04 IC,OSD LC74781 HC10377030
QL05 IC,NJM2535M TAPING TE1 HC10224090
QL06 IC,BA7622F TAPING-E2 HC10221210
QL07 IC,74HC4094 16PIN DIP HC709449B0
QL08 TRS.C2458,C1740S,C3199,ETC HT30001000
QL09 TRS.A1048,A933S,A1267,ETC. HT10001000
QL10 TRS.C2458,C1740S,C3199,ETC HT30001000
QL11 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QL12 TRS.C2458,C1740S,C3199,ETC HT30001000
QL13 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QL14 TRS.C2458,C1740S,C3199,ETC HT30001000
QL15 TRS.C2458,C1740S,C3199,ETC HT30001000
QL16 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QL17 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QL21 IC,CMOS 74HC00 FLAT
TAPING
HC700000Z0
QL22 CHIP TR. (2SC),2SC1622AD17 HX316221A0
PL04- MISCELLANEOUS
JL01 TERMINAL,YKC21-3913 1L1
FS AU
YT02011690
JL02 TERMINAL,YKC21-4074 2L2
FS AU
YT02021710
JL03 TERMINAL,YKC21-3701 1L4
FG AU
YT02041310
JL04 TERMINAL,YKC21-3701 1L4
FG AU
YT02041310
LL01 EMI FILTER,DSS306-91-F-223Z FM12223010
LL02 EMI FILTER,DSS306-91-F-223Z FM12223010
LL03 EMI FILTER,DSS306-91-F-223Z FM12223010
LL04 CHIP INDUCTANCE,
NL252018 33UH
LU15333010
XL01 CRYSTAL,
AT49/14.31818MHZ(TP)
JX14001260
PN14- RN47
CIRCUIT BOARD
PN14- RESISTORS
RN47 VARISTOR,FOR HEAT SENS.
100C BD
HP00029230
PN24- RN62
CIRCUIT BOARD
PN24- RESISTORS
RN62 VARISTOR,FOR FAN SENS.
80C BF
HP00042230
PN54- RN49
CIRCUIT BOARD
PN54- RESISTORS
RN49 VARISTOR,FOR HEAT SENS.
100C BD
HP00029230
PN64- RN86
CIRCUIT BOARD
PN64- RESISTORS
RN86 VARISTOR,FOR FAN SENS.
80C BF
HP00042230
PP04- AUX
CIRCUIT BOARD
PP04- CAPACITORS
CP03 CER.50V DC 0.1µF +80-20% DD38104010
CP04 CER.50V DC 0.1µF +80-20% DD38104010
