172
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CP05
ELECT.10µF ±20% 50V RA-2 OA10605020
CP08
CP09 CER.50V DC 0.1µF +80-20% DD38104010
CP11
ELECT.10µF ±20% 50V RA-2 OA10605020
CP14
CP16 CER.CER. 0.1µF Z 50V DA17104110
CP17 ELECT.100µF ±20% 10V RA-2 OA10701020
CP18 CER.50V DC 0.1µF +80-20% DD38104010
PP04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CP01 CP02
PP04- RESISTORS
RP11 75
Ω ±5% 1/6W GD05750160
RP12 75
Ω ±5% 1/6W GD05750160
RP14 75
Ω ±5% 1/6W GD05750160
PP04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RP01-RP06 RP16
PP04- SEMICONDUCTORS
QP01 IC,NJM4558D-D HC10008090
PP04- MISCELLANEOUS
JP01 OPT. CONNECTOR,JFJ400 YJ15000200
JP02 TERMINAL,CINCH JACK 3P +
S-TERMINAL
BY04040030
PP94- H.P.
CIRCUIT BOARD
PP94- CAPACITORS
CP93 CER.50V DC 0.1µF +80-20% DD38104010
PP94- MISCELLANEOUS
JP99 JACK,HLJ2307-01-3160 YJ01004240
PQ04- A-FUNCTION-V
CIRCUIT BOARD
PQ04- CAPACITORS
CQ01 FILM,100pF ±5% 100V APSV OF15101540
CQ02 FILM,100pF ±5% 100V APSV OF15101540
CQ07 FILM,100pF ±5% 100V APSV OF15101540
CQ08 FILM,100pF ±5% 100V APSV OF15101540
CQ13 FILM,100pF ±5% 100V APSV OF15101540
CQ14 FILM,100pF ±5% 100V APSV OF15101540
CQ19 FILM,100pF ±5% 100V APSV OF15101540
CQ20 FILM,100pF ±5% 100V APSV OF15101540
CQ25 FILM,100pF ±5% 100V APSV OF15101540
CQ26 FILM,100pF ±5% 100V APSV OF15101540
CQ31 FILM,100pF ±5% 100V APSV OF15101540
CQ32 FILM,100pF ±5% 100V APSV OF15101540
CQ39 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ40 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ43 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ44 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ48 CER.50V DC 0.1µF +80-20% DD38104010
CQ49 CER.50V DC 0.1µF +80-20% DD38104010
CQ50
ELECT.10µF ±20% 50V RA-2 OA10605020
CQ53
CQ54
CER.50V DC 0.1µF +80-20% DD38104010
CQ58
CQ64 ELECT.100µF ±20% 16V RA-2 OA10701620
CQ65 ELECT.100µF ±20% 16V RA-2 OA10701620
PQ04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CQ37 CQ38 CQ41 CQ42 CQ56
CQ59 CQ60 CQ61 CQ62 CQ63
PQ04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ01-RQ04
RQ09-RQ12 RQ17-RQ20
RQ25-RQ28 RQ33-RQ36
RQ41-RQ44 RQ49-RQ64
PQ04- SEMICONDUCTORS
QQ01 IC,NJU7312L ANALOG SW. HC10124090
QQ02 IC,NJU7312L ANALOG SW. HC10124090
QQ03 IC,NJM4560D-D HC10021090
PQ04- MISCELLANEOUS
JQ01 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
JQ02 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
JQ03 TERMINAL,14X14 RA 2L4
WH+RE AU F-FROUND
YT02041280
PS04- AUDIO FUNCTION
CIRCUIT BOARD
PS04- CAPACITORS
CS01 FILM,100pF ±10% 50V OF15101540
CS02 FILM,100pF ±10% 50V OF15101540
CS07 FILM,100pF ±5% 100V APSV OF15101540
CS08 FILM,100pF ±5% 100V APSV OF15101540
CS13 FILM,100pF ±5% 100V APSV OF15101540
CS14 FILM,100pF ±5% 100V APSV OF15101540
CS19 FILM,100pF ±5% 100V APSV OF15101540
CS20 FILM,100pF ±5% 100V APSV OF15101540
CS27 ELECT.10µF ±20% 50V RA-2 OA10605020
CS28 ELECT.10µF ±20% 50V RA-2 OA10605020
CS31 ELECT.10µF ±20% 50V RA-2 OA10605020
CS32 ELECT.10µF ±20% 50V RA-2 OA10605020
CS35 CER.50V DC 0.1µF +80-20% DD38104010
CS36 CER.50V DC 0.1µF +80-20% DD38104010
CS37
ELECT.10µF ±20% 50V RA-2 OA10605020
CS40
CS41
CER.50V DC 0.1µF +80-20% DD38104010
CS45
CS51 ELECT.100µF ±20% 16V RA-2 OA10701620
CS52 ELECT.100µF ±20% 16V RA-2 OA10701620
PS04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CS25 CS26 CS29 CS30 CS43
