Marantz SR9200 - Page 143

173
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CS46-CS50
PS04- RESISTORS
RS01 CHIP,100
Ω ±5% 1/10W NI05101110
RS02 CHIP,100
Ω ±5% 1/10W NI05101110
RS03 CHIP,270k
Ω ±5% 1/10W NI05274110
RS04 CHIP,270k
Ω ±5% 1/10W NI05274110
RS05 CHIP,0
Ω ±5% 1/10W NI05000110
RS06 CHIP,0
Ω ±5% 1/10W NI05000110
RS09 CHIP,100
Ω ±5% 1/10W NI05101110
RS10 CHIP,100
Ω ±5% 1/10W NI05101110
RS11 CHIP,270k
Ω ±5% 1/10W NI05274110
RS12 CHIP,270k
Ω ±5% 1/10W NI05274110
RS13 CHIP,0
Ω ±5% 1/10W NI05000110
RS14 CHIP,0
Ω ±5% 1/10W NI05000110
RS17 CHIP,100
Ω ±5% 1/10W NI05101110
RS18 CHIP,100
Ω ±5% 1/10W NI05101110
RS19 CHIP,270k
Ω ±5% 1/10W NI05274110
RS20 CHIP,270k
Ω ±5% 1/10W NI05274110
RS21 CHIP,0
Ω ±5% 1/10W NI05000110
RS22 CHIP,0
Ω ±5% 1/10W NI05000110
RS25 CHIP,100
Ω ±5% 1/10W NI05101110
RS26 CHIP,100
Ω ±5% 1/10W NI05101110
RS27 CHIP,270k
Ω ±5% 1/10W NI05274110
RS28 CHIP,270k
Ω ±5% 1/10W NI05274110
RS29 CHIP,0
Ω ±5% 1/10W NI05000110
RS30 CHIP,0
Ω ±5% 1/10W NI05000110
RS33 CHIP,1k
Ω ±5% 1/10W NI05102110
RS34 CHIP,1k
Ω ±5% 1/10W NI05102110
RS35 CHIP,47k
Ω ±5% 1/10W NI05473110
RS36 CHIP,47k
Ω ±5% 1/10W NI05473110
RS37 CHIP,1k
Ω ±5% 1/10W NI05102110
RS38 CHIP,1k
Ω ±5% 1/10W NI05102110
RS39 CHIP,47k
Ω ±5% 1/10W NI05473110
RS40 CHIP,47k
Ω ±5% 1/10W NI05473110
RS41 CHIP,270k
Ω ±5% 1/10W NI05274110
RS42 CHIP,270k
Ω ±5% 1/10W NI05274110
RS43 CHIP,47k
Ω ±5% 1/10W NI05473110
RS44 CHIP,47k
Ω ±5% 1/10W NI05473110
RS45 CHIP,0
Ω ±5% 1/10W NI05000110
RS49 CHIP,100
Ω ±5% 1/10W NI05101110
RS50 CHIP,0
Ω ±5% 1/10W NI05000110
RS54 CHIP,100
Ω ±5% 1/10W NI05101110
RS55 CHIP,100
Ω ±5% 1/10W NI05101110
RS56 CHIP,100
Ω ±5% 1/10W NI05101110
PS04- SEMICONDUCTORS
QS01 IC,NJU7313L ANALOG SW. HC10125090
QS02 IC,NJU7313L ANALOG SW. HC10125090
QS03 IC,NJM4560M HC10029090
PS04- MISCELLANEOUS
JS01 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
JS02 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
PS54- MULTI CH INPUT
CIRCUIT BOARD
PS54- CAPACITORS
CQ71 FILM,100pF ±5% 100V APSV OF15101540
CQ72 FILM,100pF ±5% 100V APSV OF15101540
CQ73 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ74 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ75 CER.50V DC 0.1µF +80-20% DD38104010
CQ76 CER.50V DC 0.1µF +80-20% DD38104010
CQ77 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ78 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ79 FILM,100pF ±5% 100V APSV OF15101540
CQ81 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ82 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ83 CER.50V DC 0.1µF +80-20% DD38104010
CQ84 CER.50V DC 0.1µF +80-20% DD38104010
CQ85 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ86 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ87 CER.50V DC 0.1µF +80-20% DD38104010
CS71 FILM,100pF ±5% 100V APSV OF15101540
CS72 FILM,100pF ±5% 100V APSV OF15101540
CS73 ELECT.10µF ±20% 50V RA-2 OA10605020
CS74 ELECT.10µF ±20% 50V RA-2 OA10605020
CS75 CER.50V DC 0.1µF +80-20% DD38104010
CS76 CER.50V DC 0.1µF +80-20% DD38104010
CS77 ELECT.10µF ±20% 50V RA-2 OA10605020
CS78 ELECT.10µF ±20% 50V RA-2 OA10605020
CS79 FILM,100pF ±5% 100V APSV OF15101540
CS80 FILM,100pF ±5% 100V APSV OF15101540
CS81 ELECT.10µF ±20% 50V RA-2 OA10605020
CS82 ELECT.10µF ±20% 50V RA-2 OA10605020
CS83 CER.50V DC 0.1µF +80-20% DD38104010
CS84 CER.50V DC 0.1µF +80-20% DD38104010
CS85 ELECT.10µF ±20% 50V RA-2 OA10605020
CS86 ELECT.10µF ±20% 50V RA-2 OA10605020
CS87 CER.50V DC 0.1µF +80-20% DD38104010
CS88 CER.50V DC 0.1µF +80-20% DD38104010
CS89 CER.50V DC 0.1µF +80-20% DD38104010
CS95 ELECT.100µF ±20% 16V RA-2 OA10701620
CS96 ELECT.100µF ±20% 16V RA-2 OA10701620
PS54-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CQ80 CS90-CS94
PS54- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ71-RQ74
RQ77-RQ86 RS71-RS74
RS77-RS82 RS85-RS89
PS54- SEMICONDUCTORS
QQ71 IC,NJM-2068-DD HC10053090
QQ72 IC,NJM-2068-DD HC10053090
QS70 IC,NJU7311L ANALOG SW. HC10123090
QS71 IC,NJM-2068-DD HC10053090
QS72 IC,NJM-2068-DD HC10053090
PS54- MISCELLANEOUS
JS70 TERMINAL,YKC21-3601 2L4P
FG BK AU
YT02041330
JS71 TERMINAL,YKC21-3601 2L4P
FG BK AU
YT02041330
PX04- S-VIDEO
CIRCUIT BOARD
PX04- CAPACITORS
CX05
CER.47pF ±5% CH 50V BLK DD15470300
CX08
