NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CX09 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX10 ELECT.22µF ±20% 16V RA-2 OA22601620
CX11 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX12 ELECT.22µF ±20% 16V RA-2 OA22601620
CX25
ELECT.10µF ±20% 50V RA-2 OA10605020
CX34
CX35 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX36 ELECT.22µF ±20% 16V RA-2 OA22601620
CX37 ELECT.10µF ±20% 50V RA-2 OA10605020
CX38 ELECT.10µF ±20% 50V RA-2 OA10605020
CX39 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CX40 ELECT.22µF ±20% 16V RA-2 OA22601620
CX41 CER.0.01µF Z 50V DK18103310
CX42 ELECT.10µF ±20% 50V RA-2 OA10605020
CX44 ELECT.10µF ±20% 50V RA-2 OA10605020
CX45 ELECT.100µF ±20% 10V RA-2 OA10701020
CX46 CER.50V DC 0.1µF +80-20% DD38104010
CX48 ELECT.100µF ±20% 10V RA-2 OA10701020
CX49 CER.50V DC 0.1µF +80-20% DD38104010
CX51 CER.47pF ±5% CH 50V BLK DD15470300
CX53 ELECT.10µF ±20% 50V RA-2 OA10605020
CX54 ELECT.10µF ±20% 50V RA-2 OA10605020
CX55 CER.0.01µF Z 50V DK18103310
CX56 ELECT.10µF ±20% 50V RA-2 OA10605020
CX57 CER.0.01µF Z 50V DK18103310
CX58 ELECT.10µF ±20% 50V RA-2 OA10605020
CX61 CER.0.01µF Z 50V DK18103310
CX62 ELECT.10µF ±20% 50V RA-2 OA10605020
CX64 ELECT.10µF ±20% 50V RA-2 OA10605020
CX65 ELECT.100µF ±20% 10V RA-2 OA10701020
CX66 CER.50V DC 0.1µF +80-20% DD38104010
CX68 ELECT.100µF ±20% 10V RA-2 OA10701020
CX69 CER.0.01µF Z 50V DK18103310
CX71 CER.47pF ±5% CH 50V BLK DD15470300
CX72 ELECT.10µF ±20% 50V RA-2 OA10605020
CX73 CER.0.01µF Z 50V DK18103310
CX74 ELECT.10µF ±20% 50V RA-2 OA10605020
CX75 ELECT.10µF ±20% 50V RA-2 OA10605020
CX79 ELECT.100µF ±20% 16V RA-2 OA10701620
CX80 ELECT.1µF ±20% 50V RA-2 OA10505020
CX81 ELECT.10µF ±20% 50V RA-2 OA10605020
CX82 CER.0.022µF TP050F223Z DA17223110
CX83 ELECT.100µF ±20% 16V RA-2 OA10701620
CX84 CER.0.01µF Z 50V DK18103310
CX85 ELECT.10µF ±20% 50V RA-2 OA10605020
CX86 CER.0.01µF Z 50V DK18103310
CX87 CER.0.01µF Z 50V DK18103310
CX88 ELECT.10µF ±20% 50V RA-2 OA10605020
CX89 CER.0.01µF Z 50V DK18103310
CX91 CER.20pF ±5% CH 50V BLK DD15200300
CX92 CER.20pF ±5% CH 50V BLK DD15200300
CX93 CER.47pF ±5% CH 50V BLK DD15470300
PX04- RESISTORS
RX01
75
Ω ±5% 1/6W GD05750160
RX20
RX29 75
Ω ±5% 1/6W GD05750160
RX37
75
Ω ±5% 1/6W GD05750160
RX40
PX04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RX28 RX30-RX34
RX36
PX04- SEMICONDUCTORS
QX01 IC,NJM2234D DIP TYPE HC10143090
QX02 IC,VIDEO SW NJM2296D
5IN 3OUT
HC10217090
QX03 IC,NJM2234D DIP TYPE HC10143090
QX04 IC,VIDEO SW NJM2296D
5IN 3OUT
HC10217090
QX05 IC,NJM2249D HC10221090
QX06 IC,NJM2235D HC10222090
QX07 IC,BA7622 DIP HC10220210
PX04- MISCELLANEOUS
JX01 TERMINAL,2P S-VIDEO JACK
GOLD
YT02021520
JX02 TERMINAL,2P S-VIDEO JACK
GOLD
YT02021520
JX03 TERMINAL,3P S-VIDEO JACK
GOLD
YT02030550
JX04 TERMINAL,3P S-VIDEO JACK
GOLD
YT02030550
LX01 EMI FILTER,DSS306-91-F-223Z FM12223010
LX02 EMI FILTER,DSS306-91-F-223Z FM12223010
PY04- CONNECTOR
CIRCUIT BOARD
PY04- CAPACITORS
C851 CER.0.01µF Z 50V DK18103310
C852 CER.0.01µF Z 50V DK18103310
C853 ELECT.2200µF ±20% 35V RA-2 OA22803520
C854 ELECT.2200µF ±20% 35V RA-2 OA22803520
C855
CER.0.01µF Z 50V DK18103310
C858
C859 ELECT.100µF ±20% 16V RA-2 OA10701620
C860 ELECT.100µF ±20% 16V RA-2 OA10701620
C861 CER.0.01µF Z 50V DK18103310
C862 CER.0.01µF Z 50V DK18103310
C863 ELECT,22000µF 10V EA22901010
C864 ELECT.2200µF ±20% 35V RA-2 OA22803520
C865
CER.0.01µF Z 50V DK18103310
C868
C869 ELECT.100µF ±20% 16V RA-2 OA10701620
C870 ELECT.100µF ±20% 16V RA-2 OA10701620
C871 CER.0.01µF Z 50V DK18103310
C872 CER.0.01µF Z 50V DK18103310
C873 ELECT.100µF ±20% 16V RA-2 OA10701620
C874 ELECT.100µF ±20% 10V RA-2 OA10701020
C875 ELECT.100µF ±20% 16V RA-2 OA10701620
C876 CER.0.01µF Z 50V DK18103310
C877 CER.0.01µF Z 50V DK18103310
C878 ELECT.100µF ±20% 16V RA-2 OA10701620
C879 ELECT.100µF ±20% 16V RA-2 OA10701620
CM81
CER.50V DC 0.1µF +80-20% DD38104010
CM85
CW01 ELECT.10µF ±20% 50V RA-2 OA10605020
CW02 ELECT.10µF ±20% 50V RA-2 OA10605020
CW05 ELECT.10µF ±20% 50V RA-2 OA10605020
CW06 ELECT.10µF ±20% 50V RA-2 OA10605020
