175
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PS9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CW07 CER.0.01µF Z 50V DK18103310
CW08 CER.0.01µF Z 50V DK18103310
CW31 ELECT.10µF ±20% 50V RA-2 OA10605020
CW32 ELECT.10µF ±20% 50V RA-2 OA10605020
CW35 ELECT.10µF ±20% 50V RA-2 OA10605020
CW36 ELECT.10µF ±20% 50V RA-2 OA10605020
CW37 CER.0.01µF Z 50V DK18103310
CW38 CER.0.01µF Z 50V DK18103310
CY01 CER.0.01µF Z 50V DK18103310
PY04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER. CAPACITOR ±10% 50V :
CM83 CM86
PY04- RESISTORS
R851 150
Ω ±5% 1/4W GG05151140
R852 1
Ω ±5% 1/6W GG05010160
PY04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RM81 RM83-RM85
RW01-RW04 RW31-RW34
PY04- SEMICONDUCTORS
D851
DIODE, 1D3 1A/200V HD20002710
D858
D859 DIODE,1GWJ43 HD20031050
D860 DIODE,1D3 1A/200V HD20002710
D861 DIODE, S2VB20 HE20011290
D862 DIODE,1D3 1A/200V HD20002710
D863 DIODE,1D3 1A/200V HD20002710
D864 DIODE,1D3 1A/200V HD20002710
D865 ZENER, MTZJ3.0B HD30301000
D866 DIODE,1D3 1A/200V HD20002710
D867 DIODE,1D3 1A/200V HD20002710
D868 DIODE,1D3 1A/200V HD20002710
DM81
DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
DM93
Q851 IC, NJM7815FA +15V 1A HC38915090
Q852 IC, NJM7915FA HC39915090
Q853 IC, NJM7805FA +5V HC38905090
Q854 IC, NJM7905FA HC39905090
Q855 IC, NJM7805FA +5V HC38905090
Q856 IC, BA033T +3.3V 1A TYPE HC36J33210
Q857 TRS. 2SC4793 O,Y HT347932A0
Q858 TRS. 2SC4793 O,Y HT347932A0
QM81 IC,74HC4094 16PIN DIP HC709449B0
QM82 IC,74HC4094 16PIN DIP HC709449B0
QM83
DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QM88
QM89 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QM90 DIG.TRS.DTA114ES/UN4111
10K,10K
BA10001000
QW01 IC,NJM-2068-DD HC10053090
QW31 IC,NJM4558D-D HC10008090
QY01 IC,TC74HC368AP HC736805B0
PY04- MISCELLANEOUS
F851 FUSE 2.0A 125V UL/CSA FS20200220
F852 FUSE 2.0A 125V UL/CSA FS20200220
F853 FUSE 2.0A 125V UL/CSA FS20200220
F854 FUSE 2.0A 125V UL/CSA FS20200220
