NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CN18 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN66 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
K101 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K102 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K103 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K201 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K202 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K203 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K301 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K302 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K303 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P124- SPKOUTS
FRONT SURRBACK HEAD
CIRCUIT BOARD
P124- CAPACITORS
CN10 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN11 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN12 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN95 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN96 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN97 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
P124-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C109 C110 C209
C210 C309 C310 C409 C410
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C119[/N/S] C219[/N/S]
C319[/N/S] C419[/N/S]
P124- RESISTORS
R138 4822 053 10109 10
Ω
±5% 1W GA05100010
R238 4822 053 10109 10
Ω
±5% 1W GA05100010
R338 4822 053 10109 10
Ω
±5% 1W GA05100010
R438 4822 053 10109 10
Ω
±5% 1W GA05100010
RN35 4822 052 10331 330
Ω
±5% 1/4W GG05331140
RN37 4822 052 10331 330
Ω
±5% 1/4W GG05331140
RP91 4822 053 10331 330
Ω
±5% 1W GA05331010
RP92 4822 053 10331 330
Ω
±5% 1W GA05331010
RP93 4822 052 10331 330
Ω
±5% 1/4W GG05331140
P124- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN27-RN32
P124- SEMICONDUCTORS
DN05 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN07 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DP91 4822 130 82421 DIODE,1D3 1A/200V HD20002710
QN04 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN05 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN06 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
P124- MISCELLANEOUS
J149 9965 000 12664 TERMINAL,SPKROUT FL FR YT01040880
J349 9965 000 12664 TERMINAL,SPKROUT SBL SBR YT01040880
LN01 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN03 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LP91 9965 000 05895 RELAY,HP OUT RELAY LY20240490
P134- Q111
CIRCUIT BOARD
P134- SEMICONDUCTORS
Q111 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P154- POWER AMP C SL SR,
AVSS SENS
CIRCUIT BOARD
P154- CAPACITORS
C151 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
C152 4822 126 14166 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C153 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C154 9965 000 04966 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C155 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C156 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C157 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C161 9965 000 01561 MICA,10pF D 250WV AUDIO DF31100520
C162 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C163 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C198 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C199 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C213 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C251 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
C252 4822 126 14166 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C253 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C254 9965 000 04966 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C255 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C256 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C257 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C261 9965 000 01561 MICA,10pF D 250WV AUDIO DF31100520
C262 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C263 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C351 9965 000 02015 ELECT.22µF ±20% 25V ARS OA22602540
C352 4822 126 14166 FILM,APSV 331J,
330pF(TP) 100V PP
OF15331540
C353 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
C354 9965 000 04966 FILM,APSV 122J
1200pF(TP) 100V PP
OF15122540
C355 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C356 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C357 9965 000 02644 ELECT.220µF ±20% 100V RA-2 OA22710020
C361 9965 000 01561 MICA,10pF D 250WV AUDIO DF31100520
C362 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C363 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C389 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
