Marantz SR9200 - Page 79

109
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C399 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C501
4822 126 10364 CER.100pF UP050B101K-A DA16101110
C507
C508 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
C509 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
C510 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
CN01 4822 124 90355 ELECT.100µF ±20% 50V RA-2 OA10705020
CN02 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN03 4822 124 22273 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN04 4822 124 22273 ELECT.0.47µF ±20% 50V RA-2 OA47405020
CN05 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN06 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN15 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CN17 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN61 4822 124 41535 ELECT.100µF ±20% 25V RA-2 OA10702520
CN62 4822 122 30043 CER.0.01µF Z 50V DK18103310
CN63 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN64 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CN65 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
P154-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C158 C258 C358
P154- RESISTORS
R156
4822 052 10331 330
Ω ±5% 1/4W GG05331140
R159
R163 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R164 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R167 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R168 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R173 4822 100 11452 TRIM.VARI.470 VERTICAL RA04710760
R174 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R175 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R176 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R177 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R178 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R179 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R180 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R181 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R182 9965 000 01764 FIXED,0.10
Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R192 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R193 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R199 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R256
4822 052 10331 330
Ω ±5% 1/4W GG05331140
R259
R263 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R264 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R267 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R268 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R273 4822 100 11452 TRIM.VARI.470 VERTICAL RA04710760
R274 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R275 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R276 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R277 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R278 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R279 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R280 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R281 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R282 9965 000 01764 FIXED,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R292 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R293 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R356
4822 052 10331 330
Ω ±5% 1/4W GG05331140
R359
R363 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R364 4822 052 10471 470
Ω ±5% 1/6W GG05471160
R367 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R368 4822 052 10151 150
Ω ±5% 1/6W GG05151160
R373 4822 100 11452 TRIM.VARI.470 VERTICAL RA04710760
R374 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R375 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R376 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R377 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R378 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R379 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R380 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R381 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R382 9965 000 01764 FIXED,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
R392 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R393 4822 052 10109 10
Ω ±5% 1/4W GG05100140
RN83 4822 050 24708 4.7
Ω ±5% 1/2W GG05047120
P154- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R151 R152 R154
R155 R160-R162 R165 R166
R169-R172 R183-R187 R189
R251 R252 R254 R255 R260
R261 R262 R265 R266 R269
R270 R271 R272 R283-R287
R289 R351 R352 R354 R355
R360 R361 R362 R365 R366
R369-R372 R383-R387 R389
R501-R509 R517 R530-R535
R540 R541 R545 R549
RN01-RN16 RN18-RN23 RN42
RN43 RN61 RN63-RN71 RN76
RN77 RN80 RN84 RN85
P154- SEMICONDUCTORS
D151
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D154
D155 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D156 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D157 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D158 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D159 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
D251
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D254
D255 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D256 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D257 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D258 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D259 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
