110
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
D351
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D354
D355 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D356 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D357 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D358 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D359 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
D511
4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D517
DN61 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
DN62 4822 130 10667 ZENER,4.7V EQUIVALENT HD30471000
Q151 4822 209 73064 IC,NJM-2068-DD HC10053090
Q153 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q154 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q155 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q156 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q157 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q158 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q159 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q160 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q162 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q163 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q164 4822 130 60354 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q165 4822 130 60353 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q166 9965 000 12763 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q167 9965 000 12764 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q168 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q253 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q254 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q255 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q256 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q257 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q258 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q259 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q260 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q262 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q263 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q264 4822 130 60354 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q265 4822 130 60353 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q266 9965 000 12763 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q267 9965 000 12764 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q268 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q351 4822 209 73064 IC,NJM-2068-DD HC10053090
Q353 4822 130 60107 TRS.2SA1048 Y OR GR HT110482B0
Q354 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
Q355 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q356 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q357 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
Q358 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q359 4822 130 42999 TRS.2SA1145 O OR Y TAPING HT111452A0
Q360 4822 130 43283 TRS.2SC2705 O OR Y TAPING HT327052A0
Q362 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q363 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q364 4822 130 60354 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q365 4822 130 60353 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q366 9965 000 12763 TRS.C2922 OPY 17A 200W
LF203
HT329223F0
Q367 9965 000 12764 TRS.A1216 OPY 17A 200W
LF203
HT112163F0
Q368 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
Q501 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
Q502 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN01 4822 209 83312 IC,TA7317P HC10042050
QN02 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN03 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
QN09 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
QN11 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN61 4822 209 83637 IC,NJM2901
QUAD COMPARATOR
HC10009090
QN62 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN63 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QN64 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P154- MISCELLANEOUS
K151 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K152 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K153 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K251 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K252 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K253 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
K351 4822 130 60795 KIT,A1358,C3421 O OR A1358,
C3421 Y
HK135819C0
K352 4822 130 11394 KIT,2SA1216/2SC2922 OPY
LF203
HK121619F0
K353 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
P164- SPKOUTS SURR
CENTER MULTI
CIRCUIT BOARD
P164- CAPACITORS
CN13 4822 126 10364 CER.100pF UP050B101K-A DA16101110
CN98 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CN99 /N/S 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
P164-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C159 C160 C259
C260 C359 C360
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
C140[/N/S] C169[/N/S]
C240[/N/S] C269[/N/S]
