NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
C369[/N/S]
P164- RESISTORS
R188 4822 053 10109 10
Ω ±5% 1W GA05100010
R288 4822 053 10109 10
Ω ±5% 1W GA05100010
R388 4822 053 10109 10
Ω ±5% 1W GA05100010
RN36 4822 052 10331 330
Ω ±5% 1/4W GG05331140
RN38 4822 052 10331 330
Ω ±5% 1/4W GG05331140
RN39 4822 052 10331 330
Ω ±5% 1/4W GG05331140
P164- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RN33 RN34
P164- SEMICONDUCTORS
DN06 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN08 4822 130 82421 DIODE,1D3 1A/200V HD20002710
DN09 4822 130 82421 DIODE,1D3 1A/200V HD20002710
QN07 4822 130 60839 TRS.2SC2458 Y OR GR HT324582B0
P164- MISCELLANEOUS
J199 9965 000 12663 TERMINAL,SPKROUT
CENTER SL SR
YT01060030
J299 9965 000 12664 TERMINAL,SPKROUT ML MR YT01040880
LN02 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN04 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
LN05 4822 280 70354 RELAY,VB 24MBU-510
5A/240VAC
LY20240310
P174- Q161
CIRCUIT BOARD
P174- SEMICONDUCTORS
Q161 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P214- Q211
CIRCUIT BOARD
P214- SEMICONDUCTORS
Q211 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P254- Q261
CIRCUIT BOARD
P254- SEMICONDUCTORS
Q261 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P314- Q311
CIRCUIT BOARD
P314- SEMICONDUCTORS
Q311 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P354- Q361
CIRCUIT BOARD
P354- SEMICONDUCTORS
Q361 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
P414- SBR POWER AMP
CIRCUIT BOARD
P414- CAPACITORS
C405 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
C412 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C413 4822 123 30086 MICA,47pF ±5% 500V
FE922H470JS
DF35470520
C414 4822 124 23789 ELECT,47µF/100V EA47610010
C415 4822 124 23789 ELECT,47µF/100V EA47610010
CN16 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
P414-CAPACITORS(COMMON)
PLASTIC FILM CAPACITOR
±5% 50V : C408
P414- RESISTORS
R423 4822 100 11426 TRIM.470
Ω RH0638CS2R RA04710780
R424 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R425 4822 052 10101 100
Ω ±5% 1/6W GG05101160
R426 4822 050 21022 1k
Ω ±5% 1/4W GG05102140
R427 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R428 4822 052 10479 47
Ω ±5% 1/4W GG05470140
R429 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R430 4822 052 10109 10
Ω ±5% 1/4W GG05100140
R431 4822 116 83929 220
Ω ±5% 1/4W GG05221140
R432 9965 000 01764 FIXED,0.10 Ω ±10% 5W X2
RGC55 W/TP
BZ10102020
P414- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : R421 R422 R433
R434 R435 R436 R437 R439
R548 RN44 RN45
P414- SEMICONDUCTORS
D403 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D404 4822 130 32362 DIODE,1SS176,MA165,1SS254
30V 0.1A
HD20002000
D405 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D406 4822 130 80273 ZENER,8.2V EQUIVALENT HD30821000
D407 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D408 4822 130 80837 DIODE,HSS81TD 150V 150MA
AXIAL TAPG.
HD20027010
D409 4822 130 31554 ZENER,4.3V EQUIVALENT HD30431000
Q411 4822 130 60117 TRS.C3419 Y 40V 0.8A
PC=1.2W (5W)
HT334191Y0
Q412 4822 130 63312 TRS.2SC4883 O OR Y HT348832A0
Q413 4822 130 63308 TRS.2SA1859 O OR Y HT118592A0
Q414 4822 130 60354 TRS.O,Y 120V,1A,
PC=1.5W(10W)
HT334212A0
Q415 4822 130 60353 TRS.O,Y 120V 1A
PC=1.5W(10W)
HT113582A0
Q416 9965 000 01762 TRS.2SC2922 O,Y HT329222A0
Q417 9965 000 01763 TRS.2SA1216 O,Y HT112162A0
Q418 4822 130 43233 TRS.2SC2240 GR OR BL HT322402A0
QN10 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
P414- MISCELLANEOUS
K401 4822 130 10966 KIT,2SA1358 O,2SC3421 O HK135819A0
K402 4822 130 11394 KIT,2SA1216/2SC2922(O,Y)
PAIR
HK121619F0
K403 4822 130 10965 KIT,2SA1859/C4883
O/O OR Y/Y PAIR
HK185919C0
