Marantz SR9200 - Page 82

112
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
P604- DSP AND µ-COM
CIRCUIT BOARD
P604- CAPACITORS
C610 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C611 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C612 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C613 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C614 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C615 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C616 4822 126 11568 CER.470pF (GR39) DK96471300
C617 4822 126 11703 CER.0.01µF DK98103300
C618 4822 124 90357 ELECT.2.2µF ±20% 50V RA-2 OA22505020
C619 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C620 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C621 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C622 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C640 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C641 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C642 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C643 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C644 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C645 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C646 4822 126 11568 CER.470pF (GR39) DK96471300
C647 4822 126 11703 CER.0.01µF DK98103300
C648 4822 124 90357 ELECT.2.2µF ±20% 50V RA-2 OA22505020
C649 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C650 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C651 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C652 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C670 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C671 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C672 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C673 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C674 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C675 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C676
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C685
C691 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
C692 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
C693 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR30 4822 122 33785 CER.68pF (GR39) DD95680300
CR31 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR32 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR33 4822 126 11568 CER.470pF (GR39) DK96471300
CR34 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR35 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR36 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR44 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR50 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR51 4822 126 11703 CER.0.01µF DK98103300
CR52 4822 126 11703 CER.0.01µF DK98103300
CR53 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR54 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR55 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR56 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR57 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR58 4822 122 33761 CER.22pF ±5% CG 50V GR39 DD95220300
CR59 4822 122 33761 CER.22pF ±5% CG 50V GR39 DD95220300
CR60 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR61 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR62 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR63 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CR64 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CR70 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU01 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU02 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU03 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU04 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU05 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU06 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU07 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU08 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU09 4822 126 11568 CER.470pF (GR39) DK96471300
CU12 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU13 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU14 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU15 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU16 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU17 4822 124 90352 ELECT.10µF ±20% 16V RA-2 OA10601620
CU18 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU19 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU20 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU21 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU25 5322 126 11578 CER.1000pF ±10% B 50V GR36 DK96102300
CU26 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU27 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU31 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU32 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU33 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU34 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU35 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU36 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU37 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU38 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU39 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU40 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CU41 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU42 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU43 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU44 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU45 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU46 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU47 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU50 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU51 4822 124 41539 ELECT.47µF ±20% 16V RA-2 OA47601620
CU52
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU60
CU61 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
CU62 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU63 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU64 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
CU70 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU71 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU80 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CU81 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
P604- RESISTORS
R601
4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
R607
R610 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R611 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R614
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R623
