Marantz SR9200 - 7. EXPLODED VIEW AND PARTS LIST

113
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
R624 4822 051 30223 CHIP,22k Ω ±5% 1/16W NN05223610
R626 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R629 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R630 4822 051 30333 CHIP,33k
Ω ±5% 1/16W NN05333610
R631 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R632 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R633 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R636 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R637 4822 051 30109 CHIP,10
Ω ±5% 1/16W NN05100610
R638 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R640 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R641 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R644
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R653
R654 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R656 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R657 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R658 4822 051 30333 CHIP,33k
Ω ±5% 1/16W NN05333610
R659 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R660 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R661 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
R662 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R663 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R664 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R665 4822 051 30479 CHIP,47
Ω ±5% 1/16W NN05470610
R666 4822 051 30479 CHIP,47
Ω ±5% 1/16W NN05470610
R671
4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R679
R681 4822 051 30339 CHIP,33
Ω ±5% 1/16W NN05330610
R682 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R683 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R684 4822 051 30109 CHIP,10
Ω ±5% 1/16W NN05100610
R685 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R686 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R687 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
R688 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R689 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
R691
4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
R694
RR30 4822 051 30759 CHIP,75
Ω ±5% 1/16W NN05750610
RR31 4822 051 30279 CHIP,27
Ω ±5% 1/16W NN05270610
RR32 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RR33 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RR50 4822 051 30822 CHIP,8.2k
Ω ±5% 1/16W NN05822610
RR51 9965 000 06300 CHIP,5.1k
Ω ±5% 1/16W NN0551261R
RR52 9965 000 06300 CHIP,5.1k
Ω ±5% 1/16W NN0551261R
RR53 4822 051 30759 CHIP,75
Ω ±5% 1/16W NN05750610
RR54 4822 051 30339 CHIP,33
Ω ±5% 1/16W NN05330610
RR55 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR56 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR57 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR58 4822 051 30339 CHIP,33
Ω ±5% 1/16W NN05330610
RR59 4822 051 30105 CHIP,1M
Ω ±5% 1/16W NN05105610
RR60 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RR61 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RR63 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RR65 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RR66 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RR72 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR73 4822 051 30339 CHIP,33
Ω ±5% 1/16W NN05330610
RR74 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR75 4822 051 30109 CHIP,10
Ω ±5% 1/16W NN05100610
RR76 4822 117 12139 CHIP,22
Ω ±5% 1/16W NN05220610
RR77 4822 051 30339 CHIP,33
Ω ±5% 1/16W NN05330610
RU01 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU02 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU03 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU04 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RU05 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RU06 4822 051 30101 CHIP,100
Ω ±5% 1/16W NN05101610
RU07 4822 051 30302 CHIP,3k
Ω ±5% 1/16W NN05302610
RU08 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
RU10 4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
RU11 /N 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU11 /S CHIP,1.8k
Ω ±5% 1/16W NN05182610
RU12 /N 4822 117 11817 CHIP,1.2k
Ω ±5% 1/16W NN05122610
RU12 /S CHIP,1k
Ω ±5% 1/16W NN05102610
RU12 /U CHIP,0
Ω ±5% 1/16W NN05000610
RU13 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU14 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU15 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RU17 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU20 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU21 4822 051 30123 CHIP,12k
Ω ±5% 1/16W NN05123610
RU22 4822 051 30102 CHIP,1k
Ω ±5% 1/16W NN05102610
RU24 4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RU25
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU28
RU29 4822 051 30105 CHIP,1M
Ω ±5% 1/16W NN05105610
RU31 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU32 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU37 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU38 4822 051 30101 CHIP,100
Ω ±5% 1/16W NN05101610
RU39 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU41 4822 116 83207 CHIP,1.2k
Ω ±5% 1/16W NN05122610
RU42 4822 051 30391 CHIP,390
Ω ±5% 1/16W NN05391610
RU43 4822 116 83207 CHIP,1.2k
Ω ±5% 1/16W NN05122610
RU44 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RU50 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU51 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU56 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU57 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU58 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RU60 4822 051 30479 CHIP,47
Ω ±5% 1/16W NN05470610
RU61 4822 051 30221 CHIP,220
Ω ±5% 1/16W NN05221610
RU62 4822 051 30479 CHIP,47
Ω ±5% 1/16W NN05470610
RU63 4822 116 83819 CHIP,18k
Ω ±5% 1/16W NN05183610
RU64 4822 051 30221 CHIP,220
Ω ±5% 1/16W NN05221610
RU65 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RU66 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RU67 4822 051 30221 CHIP,220
Ω ±5% 1/16W NN05221610
RU70 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU71 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU72
4822 116 82487 CHIP,0
Ω ±5% 1/16W NN05000610
RU78
RU80 4822 050 26809 68
Ω ±5% 1/4W GG05680140
RU81 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RU82 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RU83 4822 051 30682 CHIP,6.8k
Ω ±5% 1/16W NN05682610
RU84 4822 116 83963 2.2
Ω ±5% 1/4W GG05022140
RU85 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
