Marantz SR9200 - Page 87

117
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PC94- JYRO
CIRCUIT BOARD
PC94- CAPACITORS
CC90 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PC94- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RC90
PC94- SEMICONDUCTORS
QC90 4822 130 11143 PHOTO UNIT,GP1A06 2PHASE
PHOTOINTERRUPTER
HW10033320
PD04- DIG IN/ADC/DAC
CIRCUIT BOARD
PD04- CAPACITORS
CA01
4822 126 13837 CER.0.1µF ±10% B 10V DK96104200
CA05
CA06
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CA09
CA10 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CA12 4822 124 22698 ELECT.47µF ±20% 25V RA-2 OA47602520
CA14
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CA20
CD01
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CD04
CD05
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD12
CD13
9965 000 01567 ELECT.100µF 10V ARA OA10701050
CD16
CD17
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD20
CD21
4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CD24
CD25
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD28
CD29
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CD32
CD33
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD36
CD37
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CD40
CD41
4822 126 11759 CER.100pF ±5% CG 50V GR39 DD95101300
CD44
CD50
4822 126 11703 CER.0.01µF DK98103300
CD53
CD54 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD55 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CD56
4822 126 11703 CER.0.01µF DK98103300
CD59 4822 126 11703 CER.0.01µF DK98103300
CD60
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CD65
CH01
4822 121 70089 FILM,820pF ±5% 50V DF15821350
CH08
CH09
9965 000 09113 FILM,APSV 271J,
270pF(TP) 100V PP
OF15271540
CH16
CH17
4822 124 80578 ELECT.22µF 25V ARA OA22602550
CH20
CH21
9965 000 06697 FILM,APSV 561J
560pF(TP) 100V PP
OF15561540
CH24
CH25
4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CH28
CH29
4822 122 33761 CER.22pF ±5% CG 50V GR39 DD95220300
CH32
CH33
4822 124 80578 ELECT.22µF 25V ARA OA22602550
CH36
CH37
9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CH40
CH41 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CH42 4822 121 10792 FILM,APSV 221J,
220pF(TP) 100V PP
OF15221540
CH43 4822 122 33777 CER.47pF ±5% CG 50V GR39 DD95470300
CH44 4822 122 33777 CER.47pF ±5% CG 50V GR39 DD95470300
CH45 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CH46 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CH47 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CH48 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CH49
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CH56
CJ01
4822 121 70089 FILM,820pF ±5% 50V DF15821350
CJ08
CJ09
9965 000 09113 FILM,APSV 271J,
270pF(TP) 100V PP
OF15271540
CJ16
CJ17 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ18 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CJ19 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ20 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ21
9965 000 06697 FILM,APSV 561J
560pF(TP) 100V PP
OF15561540
CJ24
