Marantz SR9200 - Page 88

118
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CJ25
4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CJ28
CJ29
4822 122 33761 CER.22pF ±5% CG 50V GR39 DD95220300
CJ32
CJ33 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ34 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CJ35 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ36 4822 124 80578 ELECT.22µF 25V ARA OA22602550
CJ37
9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CJ40
CJ41
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CJ48
CK01 4822 111 41305 0
Ω ±5% 1/4W GD05000140
CK02 4822 111 41305 0
Ω ±5% 1/4W GD05000140
CK03 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CK04 4822 124 90362 ELECT.22µF ±20% 50V RA-2 OA22605020
CK05 4822 122 33753 CER.150pF ±5% CG 50V GR39 DD95151300
CK06 4822 122 33753 CER.150pF ±5% CG 50V GR39 DD95151300
CK07 4822 126 11759 CER.100pF ±5% CG 50V GR39 DD95101300
CK08 4822 126 11759 CER.100pF ±5% CG 50V GR39 DD95101300
CK09 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CK10 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CK11
4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK17
CK18 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CK19 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CK20 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CK21
4822 122 33777 CER.47pF ±5% CG 50V GR39 DD95470300
CK24
CK25 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK26 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK27 4822 122 33777 CER.47pF ±5% CG 50V GR39 DD95470300
CK28 4822 122 33777 CER.47pF ±5% CG 50V GR39 DD95470300
CK29 9965 000 08352 CER.0.1µF 50V F
C1608JF1H104Z
DK98104300
CK30 9965 000 00599 CER.0.22µF ±10% B 10V DK96224200
CK51 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK52 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK53 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CK54 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CK55 9965 000 06287 CER.GRM39F224Z16 0.22µF DK98224200
CK56 9965 000 06287 CER.GRM39F224Z16 0.22µF DK98224200
CK57 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK58 4822 126 11687 CER.GRM39F104Z16 0.1µF DK98104200
CK59 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CK60 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CK61 4822 126 11568 CER.470pF (GR39) DK96471300
CK68 4822 126 11568 CER.470pF (GR39) DK96471300
PD04- RESISTORS
RA01
4822 051 30759 CHIP,75
Ω ±5% 1/16W NN05750610
RA05
RA06
4822 051 30102 CHIP,1k
Ω ±5% 1/16W NN05102610
RA10
RA11
4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RA15
RA16
4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RA20
RA21
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RA24
RD01
4822 051 30102 CHIP,1k
Ω ±5% 1/16W NN05102610
RD08
RD09 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RH01
4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RH28
RH29
4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RH32
RH33 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RH34 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RH35 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RH36 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RH37 4822 116 83217 CHIP,560k
Ω ±5% 1/16W NN05564610
RH38 4822 116 83217 CHIP,560k
Ω ±5% 1/16W NN05564610
RH39 4822 116 83209 CHIP,120k
Ω ±5% 1/16W NN05124610
RH40 4822 116 83209 CHIP,120k
Ω ±5% 1/16W NN05124610
RH41
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RH44
RH45
4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RH48
RH49
4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RH52
RH53 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RH54 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RH55 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RH56 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RH57 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RH58 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RH59 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RH60 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RH61 4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RH62 4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RH63 4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RH64 4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RJ01
4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RJ28
RJ29
4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RJ32
RJ33 4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RJ34 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RJ35 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RJ36 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RJ37 4822 116 83217 CHIP,560k
Ω ±5% 1/16W NN05564610
RJ38 4822 051 30683 CHIP,68k
Ω ±5% 1/16W NN05683610
