119
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RJ39 4822 116 83209 CHIP,120k Ω ±5% 1/16W NN05124610
RJ40 4822 116 83209 CHIP,120k
Ω ±5% 1/16W NN05124610
RJ41
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RJ44
RJ45
4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RJ48
RJ49
4822 117 13632 CHIP,100k
Ω ±5% 1/16W NN05104610
RJ52
RK01 4822 051 30682 CHIP,6.8k
Ω ±5% 1/16W NN05682610
RK02 4822 051 30682 CHIP,6.8k
Ω ±5% 1/16W NN05682610
RK03 4822 051 30392 CHIP,3.9k
Ω ±5% 1/16W NN05392610
RK04 4822 051 30392 CHIP,3.9k
Ω ±5% 1/16W NN05392610
RK05 4822 051 30272 CHIP,2.7k
Ω ±5% 1/16W NN05272610
RK06 4822 051 30272 CHIP,2.7k
Ω ±5% 1/16W NN05272610
RK07 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RK08 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RK09 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK10 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK11
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK14
RK15
4822 051 30331 CHIP,330
Ω ±5% 1/16W NN05331610
RK18
RK19 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RK20 4822 051 30222 CHIP,2.2k
Ω ±5% 1/16W NN05222610
RK21 4822 051 30105 CHIP,1M
Ω ±5% 1/16W NN05105610
RK23
4822 051 30223 CHIP,22k
Ω ±5% 1/16W NN05223610
RK28
RK29 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK30 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK31 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK32 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK33 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK34 4822 116 83215 CHIP,5.6k
Ω ±5% 1/16W NN05562610
RK35 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK36 4822 116 83215 CHIP,5.6k
Ω ±5% 1/16W NN05562610
RK37 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK39 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK40 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK41 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK42 4822 051 30473 CHIP,47k
Ω ±5% 1/16W NN05473610
RK43 4822 051 30684 CHIP,680k
Ω ±5% 1/16W NN05684610
RK44 4822 051 30472 CHIP,4.7k
Ω ±5% 1/16W NN05472610
RK46 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK47 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK48 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK49 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RK50 4822 051 30332 CHIP,3.3k
Ω ±5% 1/16W NN05332610
RK51 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK58 4822 051 30471 CHIP,470
Ω ±5% 1/16W NN05471610
RK70
4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK73
RK74 4822 052 10681 680
Ω ±5% 1/6W GG05681160
RK75 4822 052 10681 680
Ω ±5% 1/6W GG05681160
RK76 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
RK77 4822 051 30103 CHIP,10k
Ω ±5% 1/16W NN05103610
PD04- SEMICONDUCTORS
DA01
4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DA05
DK01
4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK05
DK70 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
DK71 4822 130 81324 CHIP DIODE,1SS302 HZ20018050
QA01 4822 209 31568 IC,CMOS 74HCU04 FLAT
TAPING
HC700400Z0
QA02 4822 209 31568 IC,CMOS 74HCU04 FLAT
TAPING
HC700400Z0
QA03 9965 000 01342 IC,TC74HC151AF HC715100Z0
QA04 9965 000 01342 IC,TC74HC151AF HC715100Z0
QA05 4822 209 31929 IC,OR-GATE 74HC32 HC703200Z0
QA06 4822 209 30426 IC,CMOS 74HC00 FLAT
TAPING
HC700000Z0
QA07 5322 209 11578 IC,PCF8574I(I/O EXPANDER) HC10068490
QD01
9965 000 12651 IC,24BIT 192KHZ DAC
DR=120DB
HC10011880
QD04
QH01
4822 209 17155 IC,NJM2068M TAPING HC10102090
QH05
QJ01
4822 209 17155 IC,NJM2068M TAPING HC10102090
QJ04
QK01 4822 130 63601 CHIP TRS.(2SC),2SC4213 HX342132A0
QK02 4822 130 63601 CHIP TRS.(2SC),2SC4213 HX342132A0
QK03 4822 209 14615 IC,NJM2115M HC10172090
QK04 4822 209 14615 IC,NJM2115M HC10172090
QK05 4822 209 17155 IC,NJM2068M TAPING HC10102090
QK06 4822 209 17155 IC,NJM2068M TAPING HC10102090
QK07 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK08 4822 209 14615 IC,NJM2115M HC10172090
QK51 9965 000 09111 IC,ADC AK5383VS 96kHz24BIT HC10033480
QK70 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK71 4822 130 42292 TRS.2SC2120 O HT321201A0
QK72 4822 130 61903 DIG.TRS.DTA114EU BA10026210
QK73 4822 130 42292 TRS.2SC2120 O HT321201A0
PD04- MISCELLANEOUS
JA01 4822 267 41157 TERMINAL,14X14 RA 1L3P BLK
AU F-SHIELD
YT02030610
JA02 9965 000 01340 TERMINAL,CINCH 2P AU(BL)
FRONT SHIELDED
YT02021540
JA03
9965 000 12658 OPT.CONNECTOR,JFJ400 YJ15000200
JA06
LD01
4822 242 73843 EMI FILTER,DSS306-91-F-223Z FM12223010
LD04
LK70 9965 000 01576 RELAY,MR82-24USR LY20240480
LK71 9965 000 01576 RELAY,MR82-24USR LY20240480
PF04- SCART
CIRCUIT BOARD (/N ONLY)
PF04- CAPACITORS
CF81 /N 4822 122 30043 CER.0.01µF Z 50V DK18103310
CF82 /N 5322 124 21731 ELECT.10µF ±20% 50V RA-2 OA10605020
