Marantz SR9200 - Page 93

123
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
RM17
4822 111 90905 CHIP,220
Ω ±5% 1/10W NI05221110
RM20
RM21
4822 111 90918 CHIP,4.7k
Ω ±5% 1/10W NI05472110
RM24
RM25 2322 734 63309 CHIP,33
Ω ±5% 1/10W NI05330110
RM26 2322 734 63309 CHIP,33
Ω ±5% 1/10W NI05330110
RM31 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RM32 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RM33 4822 111 90916 CHIP,3.9k
Ω ±5% 1/10W NI05392110
RM34 4822 111 90916 CHIP,3.9k
Ω ±5% 1/10W NI05392110
RM35 4822 111 90898 CHIP,12k
Ω ±5% 1/10W NI05123110
RM36 4822 111 90898 CHIP,12k
Ω ±5% 1/10W NI05123110
RM37 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RM38 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RM39 4822 111 91191 CHIP,330
Ω ±5% 1/10W NI05331110
RM40 4822 111 91191 CHIP,330
Ω ±5% 1/10W NI05331110
RM41 4822 111 90918 CHIP,4.7k
Ω ±5% 1/10W NI05472110
RM42 4822 111 90918 CHIP,4.7k
Ω ±5% 1/10W NI05472110
RM43 4822 116 90503 CHIP,150
Ω ±5% 1/10W NI05151110
RM44 4822 116 90503 CHIP,150
Ω ±5% 1/10W NI05151110
RM60 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RM61 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RM62 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RM64 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RM65 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RM66 4822 052 10681 680
Ω ±5% 1/6W GG05681160
PG04- SEMICONDUCTORS
DE40 4822 130 33944 CHIP DIODE,DAN202K HZ20002210
DM60 4822 130 33944 CHIP DIODE,DAN202K HZ20002210
QE01 4822 209 73064 IC,NJM-2068-DD HC10053090
QE02 9965 000 01359 IC,TC9459N ELE.VOLUME HC10443050
QE03 4822 209 73064 IC,NJM-2068-DD HC10053090
QE05
4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QE08
QE40 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QE41 4822 130 60693 TRS.2SA817 O OR Y
600MW -300MA
HT108172B0
QE51 4822 209 73064 IC,NJM-2068-DD HC10053090
QE52 9965 000 01359 IC,TC9459N ELE.VOLUME HC10443050
QE53 4822 209 73064 IC,NJM-2068-DD HC10053090
QE55
4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QE58
QG01 4822 209 73064 IC,NJM-2068-DD HC10053090
QG02 9965 000 01359 IC,TC9459N ELE.VOLUME HC10443050
QG03 4822 209 73064 IC,NJM-2068-DD HC10053090
QG05
4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QG08
QG51 4822 209 73064 IC,NJM-2068-DD HC10053090
QG52 9965 000 01359 IC,TC9459N ELE.VOLUME HC10443050
QG53 4822 209 73064 IC,NJM-2068-DD HC10053090
QG55
4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QG58
QM01 4822 209 73064 IC,NJM-2068-DD HC10053090
QM02 9965 000 01359 IC,TC9459N ELE.VOLUME HC10443050
QM03 4822 209 73064 IC,NJM-2068-DD HC10053090
QM05
4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QM08
QM30 4822 209 73064 IC,NJM-2068-DD HC10053090
QM31 4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QM32 4822 130 43818 TRS.2SC2878 A OR BRANK HT328782A0
QM60 4822 130 60588 DIG.TRS.DTC114ES/UN4211
10K,10K
BA20001000
QM61 4822 130 42949 TRS.2SA970 (GR) OR (BL) HT109702A0
PG04- MISCELLANEOUS
JE01 4822 267 20445 TERMINAL,14X14 RA 2L6P BLK
AU F-SHIELD
YT02060690
JE02 9965 000 12752 TERMINAL,YKC21-3914 1L1P
FS BK AU
YT02011710
JE03 9965 000 12753 TERMINAL,YKC21-4086 2L4P
FS BK AU
YT02041340
JE04 4822 267 20445 TERMINAL,14X14 RA 2L6P BLK
AU F-SHIELD
YT02060690
JE10 9965 000 12754 RETAINER,GND TERMINAL 320J104010
LE01 9965 000 01576 RELAY,MR82-24USR LY20240480
LE51 9965 000 01576 RELAY,MR82-24USR LY20240480
LG01 9965 000 01576 RELAY,MR82-24USR LY20240480
LG51 9965 000 01576 RELAY,MR82-24USR LY20240480
LM01 9965 000 01576 RELAY,MR82-24USR LY20240480
LM60 9965 000 01576 RELAY,MR82-24USR LY20240480
PL04- CVBS
CIRCUIT BOARD
PL04- CAPACITORS
CF01 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF02 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF03 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF04 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF05 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF06 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF07 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CF08 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF09
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF13
CF14 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CF15 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CF16 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CF17 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF19 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CF20 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF21 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CF22 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF23 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CF24 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CF26 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF27 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CF28 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CF31 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CF33 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL01 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL02 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL09
4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CL12
CL13 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL14 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL15 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
