Marantz SR9200 - Page 94

124
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
CL16
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL20
CL21 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL22 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL23 9965 000 01040 ELECT.470µF ±20% 6.3V RA-2 OA47700620
CL24 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CL25 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL26 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CL27 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL28 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL29 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL32 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL34 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL35 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL36 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL37 4822 124 90357 ELECT.2.2µF ±20% 50V RA-2 OA22505020
CL38 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL39 4822 126 11591 CER.24pF ±5% CH 50V BLK DD15240300
CL40 5322 122 32143 CER.22pF ±5% CH 50V BLK DD15220300
CL42 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL44 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CL45 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CL46 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL47 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL48 /N/S 4822 122 31823 CER.15pF ±5% CH 50V BLK DD15150300
CL48 /U CER.22pF ±5% CH 50V BLK DD15220300
CL49 /N/S 4822 122 31823 CER.15pF ±5% CH 50V BLK DD15150300
CL49 /U CER.22pF ±5% CH 50V BLK DD15220300
CL50 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CL51 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL52 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL53 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CL54 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL55 4822 124 41543 ELECT.1µF ±20% 50V RA-2 OA10505020
CL57 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL58 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CL59 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CL60 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
CL63 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL64 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL65 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL66 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL67 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL68 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL69 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL70 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL71 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL72 9965 000 01569 CER.0.01µF DC50V +80%-20% DD38103010
CL73 4822 122 30103 CER.0.022µF Z 50V DK18223310
CL78 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CL79 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL80 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CL82 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CL85 4822 122 31205 CER.47pF ±5% CH 50V BLK DD15470300
CL87 4822 124 90353 ELECT.100µF ±20% 10V RA-2 OA10701020
PL04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CF25 CL43 CL62 CL83 CL86
PL04- RESISTORS
RF01 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RF02 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RF03 4822 111 90894 CHIP,75
Ω ±5% 1/10W NI05102110
RF04 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RF05 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RF06 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RF07 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RF08 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RF09
4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RF16
RL01 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL02 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL03 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL04 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL05 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL06 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL07 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL08 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL09 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL10 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL11 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL12 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL13 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL14 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL15 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL16 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL18 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL19 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL20 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL21 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL22 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL23 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL24 4822 111 91192 CHIP,470
Ω ±5% 1/10W NI05471110
RL25 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL26 4822 111 90896 CHIP,100k
Ω ±5% 1/10W NI05104110
RL27 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL28 4822 111 90898 CHIP,12k
Ω ±5% 1/10W NI05123110
RL29 4822 111 90905 CHIP,220
Ω ±5% 1/10W NI05221110
RL30 /U CHIP,0
Ω ±5% 1/10W NI05000110
RL31 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RL32 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL33 4822 111 90905 CHIP,220
Ω ±5% 1/10W NI05221110
RL35 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL36 4822 050 22201 220
Ω ±5% 1/2W GG05221120
RL37 4822 111 90918 CHIP,4.7k
Ω ±5% 1/10W NI05472110
RL38 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL39 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL40 4822 111 91077 CHIP,56
Ω ±5% 1/10W NI05560110
RL41 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL42 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL43 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RL44 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RL45 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RL57 4822 111 90895 CHIP,10k
Ω ±5% 1/10W NI05103110
RL58
4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RL61
RL62 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
RL63 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RL64 4822 111 90897 CHIP,1M
Ω ±5% 1/10W NI05105110
RL69 4822 116 81011 CHIP,75
Ω ±5% 1/10W NI05750110
