126
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PP94- H.P.
CIRCUIT BOARD
PP94- CAPACITORS
CP93 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
PP94- MISCELLANEOUS
JP99 4822 265 10685 JACK,HLJ2307-01-3160 YJ01004240
PQ04- A-FUNCTION-V
CIRCUIT BOARD
PQ04- CAPACITORS
CQ01 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ01 /U FILM,100pF ±5% 100V APSV OF15101540
CQ02 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ02 /U FILM,100pF ±5% 100V APSV OF15101540
CQ07 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ07 /U FILM,100pF ±5% 100V APSV OF15101540
CQ08 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ08 /U FILM,100pF ±5% 100V APSV OF15101540
CQ13 /N/S 9965 000 05891 FILM,APSV 471J,4
70pF(TP) 100V PP
OF15471540
CQ13 /U FILM,100pF ±5% 100V APSV OF15101540
CQ14 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ14 /U FILM,100pF ±5% 100V APSV OF15101540
CQ19 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ19 /U FILM,100pF ±5% 100V APSV OF15101540
CQ20 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ20 /U FILM,100pF ±5% 100V APSV OF15101540
CQ25 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ25 /U FILM,100pF ±5% 100V APSV OF15101540
CQ26 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ26 /U FILM,100pF ±5% 100V APSV OF15101540
CQ31 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ32 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ39 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ40 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ43 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ44 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ48 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ49 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ50
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ53
CQ54
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ58
CQ64 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CQ65 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CS80 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
PQ04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CQ31[/U] CQ32[/U] CQ37 CQ38
CQ41 CQ42 CQ56 CQ59 CQ60
CQ61 CQ62 CQ63
PQ04- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ01-RQ04
RQ09-RQ12 RQ17-RQ20
RQ25-RQ28 RQ33-RQ36
RQ41-RQ44 RQ49-RQ64
PQ04- SEMICONDUCTORS
QQ01 4822 209 16842 IC,NJU7312L ANALOG SW. HC10124090
QQ02 4822 209 16842 IC,NJU7312L ANALOG SW. HC10124090
QQ03 4822 209 83274 IC,NJM4560D-D HC10021090
PQ04- MISCELLANEOUS
JQ01 9965 000 07097 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
JQ02 9965 000 07097 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
JQ03 4822 267 31823 TERMINAL,14X14 RA 2L4
WH+RE AU F-FROUND
YT02041280
PS04- AUDIO FUNCTION
CIRCUIT BOARD
PS04- CAPACITORS
CS07 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS07 /U FILM,100pF ±5% 100V APSV OF15101540
CS08 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS08 /U FILM,100pF ±5% 100V APSV OF15101540
CS13 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS13 /U FILM,100pF ±5% 100V APSV OF15101540
CS14 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS14 /U FILM,100pF ±5% 100V APSV OF15101540
CS19 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS19 /U FILM,100pF ±5% 100V APSV OF15101540
CS20 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS20 /U FILM,100pF ±5% 100V APSV OF15101540
CS27 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS28 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS31 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS32 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS35 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS36 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS37
4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS40
CS41
4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS45
CS51 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CS52 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
PS04-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CS25 CS26 CS29 CS30 CS43
CS46-CS50
