NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
SR9200
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PS04- RESISTORS
RS09 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS10 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS11 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS12 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS13 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS14 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS17 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS18 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS19 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS20 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS21 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS22 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS25 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS26 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS27 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS28 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS29 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS30 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS33 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS34 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS35 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS36 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS37 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS38 4822 111 90894 CHIP,1k
Ω ±5% 1/10W NI05102110
RS39 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS40 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS41 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS42 4822 111 90912 CHIP,270k
Ω ±5% 1/10W NI05274110
RS43 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS44 4822 111 90919 CHIP,47k
Ω ±5% 1/10W NI05473110
RS46 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS49 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS51 4822 111 90892 CHIP,0
Ω ±5% 1/10W NI05000110
RS54 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS55 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
RS56 4822 111 90893 CHIP,100
Ω ±5% 1/10W NI05101110
PS04- SEMICONDUCTORS
QS01 4822 209 16843 IC,NJU7313L ANALOG SW. HC10125090
QS02 4822 209 16843 IC,NJU7313L ANALOG SW. HC10125090
QS03 4822 209 83357 IC,NJM4560M HC10029090
PS04- MISCELLANEOUS
JS01 4822 267 31823 TERMINAL,14X14 RA 2L4
WH+RE AU F-FROUND
YT02041280
JS02 9965 000 07097 TERMINAL,14X14 RA 2L6
WH+RE AU F-GROUND
YT02060670
PS54- MULTI CH INPUT
CIRCUIT BOARD
PS54- CAPACITORS
CQ71 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ71 /U FILM,100pF ±5% 100V APSV OF15101540
CQ72 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ72 /U FILM,100pF ±5% 100V APSV OF15101540
CQ73 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ74 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ75 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ76 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ77 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ78 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ79 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CQ79 /U FILM,100pF ±5% 100V APSV OF15101540
CQ81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ82 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ83 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ84 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CQ85 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ86 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CQ87 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS71 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS71 /U FILM,100pF ±5% 100V APSV OF15101540
CS72 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS72 /U 9965 000 01344 FILM,100pF ±5% 100V APSV OF15101540
CS73 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS74 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS75 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS76 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS77 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS78 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS79 /N/S 9965 000 05891 FILM,APSV 471J,
470pF(TP) 100V PP
OF15471540
CS79 /U FILM,100pF ±5% 100V APSV OF15101540
CS80 /U FILM,100pF ±5% 100V APSV OF15101540
CS81 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS82 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS83 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS84 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS85 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS86 4822 124 22571 ELECT.10µF ±20% 50V RA-2 OA10605020
CS87 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS88 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS89 4822 122 40617 CER.50V DC 0.1µF +80-20% DD38104010
CS95 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
CS96 4822 124 90354 ELECT.100µF ±20% 16V RA-2 OA10701620
PS54-CAPACITORS(COMMON)
HIGH DIELECTRIC CONSTANT
CER.CAPACITOR ±10% 50V :
CQ80 CS90-CS94
PS54- RESISTORS(COMMON)
CARBON FILM FIXED RES.
±5% 1/6W : RQ71-RQ74
RQ77-RQ86 RS71-RS74
RS77-RS82 RS85-RS89
PS54- SEMICONDUCTORS
QQ71 4822 209 73064 IC,NJM-2068-DD HC10053090
QQ72 4822 209 73064 IC,NJM-2068-DD HC10053090
QS70 4822 209 16149 IC,NJU7311L ANALOG SW. HC10123090
QS71 4822 209 73064 IC,NJM-2068-DD HC10053090
QS72 4822 209 73064 IC,NJM-2068-DD HC10053090
PS54- MISCELLANEOUS
JS70 9965 000 12766 TERMINAL,YKC21-3601 2L4P
FG BK AU
YT02041330
JS71 9965 000 12766 TERMINAL,YKC21-3601 2L4P
FG BK AU
YT02041330
