101
UD9004
L101 00D2390038023 00D2390038023 L.FILTER(HR28RE332)
L102 111010010249S 111010010249S INDUCTOR(PC13-3R9N)
L103 111810014502S 111810014502S INDUCTOR 10UH(7E10H)
L104 00D2350185903 00D2350185903 INDUCTOR 47UH(7E10H)
L105 111810020507S 111810020507S CDEP147NP-5R9MC73
RL101 00D2140242001 00D2140242001 RELAY(DLS9D1-O_M)
RL102 682010007608S 682010007608S RELAY(DQ12D1-0(M))
RL103 00D2140222908 00D2140222908 RELAY(EE2-24N35) +REF
RL104 682010007608S 682010007608S RELAY(DQ12D1-0(M))
ST101 00D2050452017 00D2050452017 STYLE PIN
z T101 102010009009S 102010009009S SW_TRANS(E2 3912) for N, S, R
z T102 00D2336614003 00D2336614003
POWER TRANS(MINI/E3) for U
z T102 00D2336615002 00D2336615002
POWER TRANS(MINI/E2) for N, S, R
TH101 252010002200S 252010002200S
NTPAN4R0LDKB0
W101,W102 nsp nsp GND TERMINAL FOR PCB
W105 nsp nsp GND TERMINAL FOR PCB
W107-W111 nsp nsp GND TERMINAL FOR PCB
W112 nsp nsp GND TERMINAL FOR PCB
W301,W302 nsp nsp GND TERMINAL FOR PCB
W405 00D2051034007 00D2051034007 M3 SCREW TERMINAL
W407 00D2051034007 00D2051034007 M3 SCREW TERMINAL
0RD4700051009 0RD4700051009 3X8 CPS(SW,W) ZNP
00D4610991026 00D4610991026 RUBBER SHEET
Ref. No.
Part No.
(for EUR)
Part No. Part Name Remarks Q'ty New
s
s
