Marantz UD9004/U1B - Page 104

102
UD9004
8U-37AK550002 MAIN PWB UNIT ASSY(U model)
8U-37AK550003 MAIN PWB UNIT ASSY(N model)
8U-37AK550004 MAIN PWB UNIT ASSY(S model)
8U-37AK550005 MAIN PWB UNIT ASSY(R model)
Ref. No.
Part No.
(for EUR)
Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC101 nsp nsp
R8A34019BG
IC105 nsp nsp K4T1G084QQ-HCE6
IC106 nsp nsp LP2996MX
IC107 nsp nsp K4T51163QG-HCE6
IC108 nsp nsp K4T51163QG-HCE6
IC109 nsp nsp LP2996MX
IC110 nsp nsp BE ROM SUB ASSY
(S29GL01GP11TFCR20#)
IC112 nsp nsp
SN74LVC1G08DBV +C
IC200 nsp nsp RTL8201CP
IC201 nsp nsp SN74LV594APWR
IC202,203 nsp nsp TC74VHC244FT
IC204 nsp nsp SN74LV594APWR
IC205,206 nsp nsp EN5336QI-T
IC207 nsp nsp EN5322QI-T
IC208 nsp nsp EN5366QI-T
IC351 nsp nsp EP3C40F484C8N
IC352 nsp nsp BA25BC0FP-E2
IC354 nsp nsp EPCS16SI8N
IC355 nsp nsp RN5RZ50B-TR
IC451 nsp nsp W9864G2GH-6
IC452 nsp nsp ADSP21367KSWZ2AA1UD1
IC453 nsp nsp DSP1 ROM SUB ASSY
(W19B160BBT7H)
IC551 nsp nsp W9864G2GH-6
IC552 nsp nsp ADSP21367KSWZ2AA1UD2
IC553 nsp nsp DSP2 ROM SUB ASSY
(W19B160BBT7H)
IC602 nsp nsp
FCXO-05B(22.5792MHz)
IC609 nsp nsp FCXO-05B(24.576MHz)
IC651 nsp nsp AK4101AVQ
IC652 nsp nsp LC89057W-VF4A
IC656 nsp nsp GP1FAV55TK0F
IC703 nsp nsp BD18KA5FP-E2
IC704-706 nsp nsp BU7331EKN-E2
IC707 nsp nsp SN74LVC04APW-EL2
IC708 nsp nsp SN74LVC157APW-EL2 +C
IC709 nsp nsp SN74LVC157APW-EL2 +C
IC710 nsp nsp SN74LVC157APW-EL2 +C
IC714 nsp nsp SN74LVC74APWR
IC715 nsp nsp SM8707HV-G-E2
IC718 nsp nsp BU2365FV-E2
IC719 nsp nsp SM5158AM-G-E2
IC851 nsp nsp BD4730G-TR
IC852 nsp nsp S-24CS08AFJ-TB +C
IC853 nsp nsp SYSTEM ROM SUB ASSY
(
R5F364VDNFB )
IC854 nsp nsp SN74LVC157APW-EL2 +C
IC855 nsp nsp SN74LVC157APW-EL2 +C
TR301,302 nsp nsp KRC102S-RTK/P (10K-10K)
TR451 nsp nsp KRC102S-RTK/P (10K-10K)
TR452,453 nsp nsp KRA102S-RTK/P (10K-10K)
NOTE :
When update Firmware, please
confirm a last version in SDI.
Use the service board after
updating it.
