(2) Remove the screws. Disconnect the connector wire and FFC Cable.
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.
2. AUDIO SUR/BACK/S_W UNIT
(1) Remove the screws.
(2) Disconnect the connector wires and FFC cables then remove the screws.
FFC Cable
JF08JF02
Proceeding : TOP COVER →
→
SIDE COVER (L) and (R) SUB ASSY
AUDIO SUR/BACK/S_W UNIT
Direction of photograph: A
FFC Cable
JG51
JG52
To Next Page
