Marantz ZR6001 - Page 92

112
NO
TE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
7 .1CH PREOUT PWB
(
CUP11857-6
)
7.1PRE BN22 ns
p
ns
p
CORD WIRE ASSY CWB1B915280EN
7 .1PRE C170 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C171 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C172 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C173 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C174 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C175 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C176 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE C177 ns
p
ns
p
CER. CAP. 470PF 50V KB CCKT1H471KB
7 .1PRE JK15 90M-YT004040R 90M-YT004040R TERMINAL RCA-401DA-28 CJJ4P051Z
7.1PRE JK16 90M-YT004050R 90M-YT004050R TERMINAL RCA-401DA-16 CJJ4P052Z
AMP PWB
(
CUP11824Z
)
AMP ns
p
ns
p
CLAMPER K HR301
AMP ns
p
ns
p
CLAMPER K HR301
AMP ns
p
ns
p
SCREW C TB3+6J
AMP S9 ns
p
ns
p
SCREW C TB3+8J
AMP S12 ns
p
ns
p
SCREW C TW3+8J
AMP BN23 ns
p
ns
p
CORD WIRE ASSY CWZSR7400BN23
A MP BN24 ns
p
ns
p
CORD WIRE ASSY CWZSR7400BN24
A MP BN25 ns
p
ns
p
CORD WIRE ASSY CWB1B905180EN
A MP BN70 ns
p
ns
p
CORD WIRE ASSY CWZSR5500BN70
A MP C401 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C402 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C403 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C404 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C405 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A MP C406 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A MP C407 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C408 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C409 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
A MP C410 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
A MP C411 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C412 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C413 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C414 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C419 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
A MP C420 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
A MP C421 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
A MP C422 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
A MP C501 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C502 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C503 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C504 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C505 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A MP C506 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A MP C507 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C508 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C509 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
A MP C510 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
A MP C511 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C512 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C513 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C514 ns
p
00MOA10706320 ELECT CAP. 100UF 63V CCEA1JH101E
A MP C519 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
A MP C520 ns
p
00MOA10705020 ELECT CAP. 100UF 50V CCEA1HH101T
A MP C521 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
A MP C522 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
A MP C601 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C602 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
A MP C603 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C604 ns
p
ns
p
CER. CAP. 330PF 50V KB CCKT1H331KB
A MP C605 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A MP C606 ns
p
ns
p
CER. CAP. 10PF 50V DC CCCT1H100DC
A
MP C607 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C608 90M-OF100350R 90M-OF100350R FILM CAP. 2200PF 50V J HCQI1H222JZT
AMP C609 ns
p
00MOA22605020 ELECT CAP. 22UF 50V CCEA1HH220T
P
OS. NO.
