EXPLODED VIEWTECHNICAL PARAMETERS
TEMPERATURE INCREASE CHART
TECHNICAL SPECIFICATIONS GAS 6 FLOW GAS 10 FLOW
* No need for electricity, starts with pulse ignition, powered by 2 D cell batteries. Not included.
Gas Type
Heat Loss
Maximmum Flow Rate
Exhaust Discharge Mode
Ignition
Activation Pressure
Safe Operating Water Pressure
Hot Water Output per Minute
Min & Max Gas Inlet Pressure
Water Connections
Dimensions
Weight
U.E.F.
Liquid Propane or Natural Gas
42,000 BTU/h
1.58 GPM - 6 LPM
Flue Duct Type
2D Cell Battery Powered
2.5 PSI
2.5 PSI -116 PSI
6L / min
Natural Gas:
0.87kPa - 2.61 kPa
Liquid Propane:
1.99kPa - 3.23kPa
1/2" NPT
17.3" X 11.8" X 5.1"
10 lbs
Natural Gas: 0.867
Liquid Propane: 0.823
Liquid Propane or Natural Gas
65,000 BTU/h
2.64 GPM - 10 LPM
Flue Duct Type
2D Cell Battery Powered
2.5 SPI
2.5 PSI - 116 PSI
10L / min
Natural Gas:
0.87kPa - 2.61 kPa
Liquid Propane:
1.99kPa - 3.23kPa
1/2" NPT
21.65" X 12.9" X 7.28"
24 lbs
Natural Gas: 0.823
Liquid Propane: 0.823
TEMP. INCREASE PER GPM
GAS 6 FLOW
Highest Lowest Highest Lowest
GAS 10 FLOW
GPM
0.5
1.0
1.5
2.0
2.5
2.7
3.0
126˚F
64˚F
43˚F
32˚F
-
-
-
34˚F
17˚F
11˚F
9˚F
-
-
-
-
100˚F
67˚F
50˚F
40˚F
37˚F
30˚F
68˚F
34˚F
23˚F
17˚F
14˚F
13˚F
9˚F
This information is intended as a guideline based on typical residential environments. Temperature
increases will vary depending on the environment in which the heater is used. Variables such as very low
incoming water temperature or higher than average gas pressure can result in higher temperature
increases. Higher incoming water temperature or lower than average gas pressure can result in lower
temperature increases. ALWAYS test the water with your hand to confirm suitable temperature before use.
*Highest gas setting:
set Winter/High
*Lowest gas setting:
set for Summer/Low
Temperature increases listed are based on use of the water heater under optimal
conditions with an incoming water temperature of 48°F. Variable factors such as incorrect
or imperfect installation or warmer incoming water temperature may yield different results.
