16
N
0
536 MONAURAL / N
0
534 DUAL-MONAURAL AMPLIFIER / OWNER’S MANUAL
APPENDIX
RS232 CHART
Cable Connections
RJ25/RJ11 Pin 2 goes to DB-9 Pin 3
RJ25/RJ11 Pin 3 goes to DB-9 Pin 2
RJ25/RJ11 Pin 5 goes to DB-9 Pin 5
DB9 Pins
Exit Standby Mode !1038 1 – NOT USED NO CONNECTION 1 – NOT USED NO CONNECTION
Enter Standby Mode !1039 2 – Data Receive 2 – Data Receive
3 –
Data Transmit 3 – Data Transmit
4
– NOT USED NO CONNECTION 4 – NOT USED NO CONNECTION
STATUS !1061
5
–
Digital Ground 5 – Digital Ground
Set Normal Standby Mode !1062
6 – NOT USED NO CONNECTION
Set Green Standby Mode !1063
7 – NOT USED NO CONNECTION
Set Power Save Standby
Mode
!1064
8 – NOT USED NO CONNECTION
9 – NOT USED NO CONNECTION
Settings
115200 Baud
8 Bits
No Parity
the return prompt will be
Invalid command?
When code is entered correctly
return prompt will be OK:
6 – NOT USED NO CONNECTION
RS-232 Control Codes
RJ25/RJ11 Pins
№ 536/534 RS-232 Guide
When code is entered incorrectly
1 Stop Bit
Display Network
Information
ipconfig
RJ25/RJ11 - Top View of Pins
(clip facing down)
DB9 Female -
Front view of Connector
APPENDIX
