9 Options
Settings (Omron E5CN)
The values shown below are given for information only.
The parameters specific to the units are delivered with the CD (they can also be stuck inside the
electrical panel).
Symbol Type Value
Adjustment
P Proportional strip 0.9
ITotal time65
d Diversion time 11
Setting
CN-T 1
dU °C
SL-H Max setpoint 35
SL-L Min setpoint 20
CNTL PID
S-HC Stnd
St OFF
Orew d
PtRN OFF
ALt1 Type 1 alarm 1
ALH1 Hysteresis 1
ALt2 Type 2 alarm 1
ALH2 Hysteresis 1
To access advanced functions:
AMoV Change the value from 0 to -169
Advanced functions
Sb1N N-C
Sb2N NO
At-H 0.1
Out 1 0
SUb1 High&Low temperature ALM 1
SUb2 ALM2
Operation
Al-1H Too hot 10
Al-1L Too c o l d 10
Al-2H Too hot 10
Al-2L Too c o l d 10
