MARLO MGT 240 - Page 36

MGT 240M–1200M 3” NXT2 - SYSTEM 14 DEMAND
OPERATION
32
NXT2 WIRING DIAGRAM
VDM
VDM
VDM
IMPORTANT: DO NOT USE P18 TO POWER NON-PENTAIR DEVICES; USE AUX1 & AUX2 INSTEAD
FLOW METER (FM) WIRING
GROUND ( - ) POWER ( + ) SIGNAL
FLECK BLACK RED GREEN
SIGNET SHIELD BLACK RED
CLACK BLACK RED WHITE
AUTOTROL CLEAR RED BLACK
