25
MGT 2” 60M–600M NXT2 TWIN ALTERNATING
OPERATION
RAPID RINSE POSITION
Hard water ows thru the regenerating valve directly down thru the mineral into the bottom distributor and up thru the
center tube — around the piston and out the drain line.
BRINE
LEVEL
BRINE
TANK
FLOW CONTROL
INLET
OUTLET
DRAIN
BRINE VALVE
RESIN
TANK
