CashFlow
®
129 System Installation
The system consists of a channel, Y-chute, CashFlow
®
129 validator, 8-way separator,
manifold and tube collar plate.
This is supplied as a complete system, but should you need to replace any part of it do so
only in a set sequence, starting from near the top.
+ The Y-chute can, of course, be removed first, but it is not necessary to do so just to access the
other modules.
Removal of Validator and Separator
q Ensure that power is turned off, not only to the validator, but also to the Y-chute if
live.
q Dis-connect machine interface loom, and the route inhibit connector.
q Dis-engage the release catch and lift the validator and separator upwards out of
the mounting points. Pull the validator and separator forwards clear of channel.
8 ©, Mars, Inc., 1998
CashFlow
®
126 and CashFlow
®
129 selectors User Guide
